E Clamping element for welding table 0 Version 37 7150- High-quality 2-part plastic handle. 37 7151 - Clamp handle with rounded ends. 37 7152 - Lever handle with locking mechanism for proportionate and vibration-proof clamping. i Can be incorporated in to the welding table without using tools, i Wide variety of uses. i Convenient, secure, pin-point individual clamping, i Steplessly adjustable. Advantage Type mm 16/100 28/120 28/140 16/150 28/175 a 37 7150 Clamping element, 2-component handle ft 377151 Clamping element, knob handle ft 37 7152 Clamping element, lever handle Hole 0 mm 16 28 28 16 28 Clamping height max. mm 200 300 300 200 300 Series mm 100 120 140 30-150 40-175 Version rigid variable Vario table clamping set Version 377152J6/100 377151 16/100 377150J6/100 37 7150_16/150 variable v Application Size VAD - without pin, for movement on the welding table. Size 16VAD / 28VAD - with pin, for insertion into the welding table. Suitable for round, oval and angular workpieces. Stepless angular adjustment from 60° acute to 60° oblique. Type 16VAD 28VAD VAD ft 37 7160 Table clamping set (set of 2) Hole 0 mm 16 28 Clamping face width mm 45 377160_VAD tknomacneie' UniPower electro-permanent magnetic clamping plate Version Innovative and patented monoblock design for maximum stiffness and reliability. Threaded sockets of high-tensile material in each pole. Magnetic face formed of modular pole plates. Advantage Vibration-free roughing machining to protect the tool and the machine. Five-axis machining without interference contours. Full exploitation of the machine travel. Minimum set-up times, quick assembly of individual magnetic clamping devices. Quick and precise plane-parallel milling. Uniform clamping force over the entire clamping area. Application For use in mould-making, tool-making and machine tool building. Supplied with ST200F controller. Optional extras Pole extension No. 382010. Type 406UP 408UP 508UP iraoMaanr UniPower 8 38 2000 electro-permanent magnetic clamping plate Length xwidthx height mm 600 x400 x 51 790x400x51 790 x480x51 Number of poles 24 32 40 Pole pitch mm 62 62 62 Maximum clamping force kN 145 193 241 Weight kg 90 115 135 Pole extension Suitable for No. 38 2000 Type PFR PMQ 382010 naoMiacir Pole extension for the UniPower electro-permanent magnetic damping plate 0 mm 60 Version fixed moveable Height mm 41 41 Length x width mm - 60x60 382000 Controls 382010 PFR 382010_PMQ 382000 792 Main catalogue Hoffmann Group 46
