Hoffmann Group 47 <1.2 Auarant individual components of tool block insertion frame The side pieces can be fitted individually with carrier rails No. 970110 and tool carriers. The modules can be fitted horizontally or at an angle. Size SK30-HSK100 - Fitted with 3 tool carriers. Size 0 - Side pieces with cross braces; for individual fitting. Colour: Light grey RAL 7035 powder-coated. Note: VDI20 sockets also suitable for TRUMPF stamping punches. 97 0505 for tool shanks SK40 SK50 1 VDI20 I VDI30 VDI40 C4 C5 I C6 1 a.’/ill’ll V Tool block insertion frame Width 500 mm 332.24 320.85 296.01 296.01 323.96 320.85 318.78 316.71 301.19 Height mm 327 Depth mm 550 Number of tool sockets 36 27 12 54 36 27 15 15 16 Axial spacing A mm 69 85 117 52 69 85 82 82 128 for tool shanks HSK40 I HSK50 I HSK63 HSK100 I 0 1 BrfiTITM Tool block insertion frame Width 500 mm 358.11 343.62 331.20 315.68 318.78 79.49 Height mm 327 Depth mm 550 Number of tool sockets 51 27 27 12 12 - Axial spacing A mm 56 76 76 108 111 - I “4 1000kg . 100% -kttn Garant Workbench for CNC machines Colour: Note: Body light grey RAL 7035, drawers mouse grey RAL 7005 powder-coated. For storage of tools, a drawer inlay Na 970700 is required. Workbench 1500 mm long, worktop depth 800 mm With 1 drawer unit 717 mm wide (36x36 units) and 1 support stand. Application: The drawer unit can be fitted on the left- or right- hand side. Non-warping beech marine ply, with waterproof glue; finished with clear varnish. No. 933578 Illustration: Front heigh r in mm / maximum load capacity in kg. Fronthoheinmm/ maximale Belastbarkeit in kg 50/75 50/75 Worktop length mm 1500 1 Workbench with 1 support stand and 1 drawer unit 36x36 units 1218.20 Height 850 Worktop length mm 1500 Worktop depth mm 800 Worktop thickness mm 50 Drawer cabinet right WxDxH mm 717X725X800 Drawers usable width (body on the right) mm 612 Drawers usable depth (body on the right) mm 612 Weight kg 175 970600 Dividers cart be found under drawer cabinets No. 96 0250 - 960360 as sets and also under No.960490 - 96 0700 as individual parts. 447
