iso metric (u-type) U-Type n U Designation 1 41 cn -l P A f Application: General Industry Insert IC Pitch Type (inch) (mm) L R X Y (inch) (inch) (inch) (inch) 22UERL5.50ISO External Neutral U-Type 0.500 5.50 NA 0.866 0.028 0.091 0.433 22UERL5.50ISO External Neutral U-Type 0.500 5.50 NA 0.866 0.028 0.091 0.433 22UERL6.00ISO External Neutral U-Type 0.500 6.00 NA 0.866 0.031 0.102 0.433 27UERL8.QQISO External Neutral U-Type 0.625 8.00 NA 1.063 0.043 0.094 0.539 ) P O M O K N ) S O H TPI Hand TAEG-1l 7e 1191
