HeliCbNplU Thread repair - DIN 8140 m d byBtn.LHOFF I 1 Threaded inserts Version 08 2808- Insertion tool for HeliCoil thread inserts. 082810-2818- Metric threaded inserts of stainless steel wire, which resemble springs. Free-running thread, pitch for pitch, the drive tag is broken off at the notch (design fracture point) after installation. Optimised shape with innovative introduction zone that allows the insert to be attached and turned like a screw to insert it. Supplied with 08 2810-2814 Size M2 - M6 - Set of 20 pieces. 082810-2814 SizeM8- M16- Set of 10 pieces. 3; Type/size of thread M2 M2,5 M3 M4 M5 M6 M8 M8x1 M10 MIOxI M12 M14 M16 1082808 Insertion spindle 082810 Thread insert pack 10 or 20 pieces 1 xD 082812 Thread insert pack 10 or 20 pieces 1.5 xD 082814 Thread insert pack 10 or 20 pieces 2xD Set contents (08 2810,08 2812,08 2814) pcs. 20 20 20 20 20 20 10 10 10 10 10 10 10 Type/size of thread M3 M4 M5 M6 M8 M10 M12 no ooi o Thread insert pack 3 082818 ioo pieces 1.5 xD Set contents pcs. 100 Universal thread repair tool Version Universal thread cut-to-length tool for external threads. Quick attachment using the adjustment screw. Blade automatically adjusts to any thread lead. For cutting right-hand and left-hand threads to length (take into account the thread direction ). Suitable for all types of thread (60° flank angle). For thread 0 mm 4-13 16-38 2 no iocc Universal 08 2855 thread repair tool koto Screw / nut extractor for right-hand threads Version Made of tough chrome molybdenum steel. The sharp edges of the flutes bite into the jammed or broken screw/nut and allow it to be unscrewed. For use in conjunction with a tommy bar, ratchet etc. Application For extracting jammed or broken screws, nuts, and bolts. Suitable also for round-head and socket-head screws. Suitable for size across flats mm 8 10 13 15 16 17 19 22 24 082890 2 External 0xlenqth mm 13x32 15.8x32 19.7x32 22.5x32 23.9x32 25.8x42 28.4x42 32x42 35x42 Suitable for screws M 5 M 6 M 8 - M 10 M 10 M 12 M 14 M 16 Square drive 3/8" 3/8" 3/8" 3/8” 3/8” 1/2" 1/2" 1/2” 1/2" Screw / nut extractor set Set contents pcs. 5 m -JOQ-) Screw / nut o uo 4.0 extractor set 5 pieces Contents 5x screw extractors No. 082890 Size 10; 13; 17; 19; 24 Main catalogue Hoffmann Group 46 1545
