Mahr 7-4 Millimar Electrical Length Measuring Instruments Millimar Electrical Length Measuring Instruments INDUCTIVE PROBE PROGRAM P1300-Series (Mahr-Half bridge) Available in Mahr and Tesa compatibilities Well-proven and established Mahr-Half Bridge technology Easy to service cable and probe can be seperated via the plug-in connector Simple to change to pneumatic lifting Measuring spindle runs in rotary stroke bearings Page 7-6 P1300 A s P1300B P2000-Series r P2001 P2004 P2010 A P2104 A Available in all prominent compatibilities Mahr Mahr-Federal Tesa Marposs) Wide product spectrum; measuring ranges from 1 to 10 mm plus models with a compressed air (pneumatic) lifter or with vacuum retraction With rotary stroke bearings (except P2001) High linearity over the total measuring range Excellent electromagnetic shielding (EMC) All probes (except P2001) can be easily converted from axial to radial by mounting a slip on cap included in the scope of supply Page 7-10 1301 1303 1304 K 1318 (Mahr-Lvdt) ehe-Series (Federal-Lvdt) r 1301 1303 1304 K 1318 EHE-2056 Extremely robust in all operating conditions; measuring system is offset to guide and mounting shank Excellent clamping characteristics Measuring spindle runs in rotary stroke bearings (except 1318) Measuring spindle can be lifted with a cable release (1301 1303) Gaging pressure is less than 4g .14 oz in either direction with a change of less than 0.1 g per 25 m .0001" of contact travel and linearity of 0.1% over the full range 0.250 mm .010" also clutch-mounted contact swivels through 280 arc for easy positioning (EHE-Series) Page 7-14 7-16 1340 Mahr high Precision Probe
