Фрезерный инструмент Iscar с твердосплавными режущими пластинами Длиннокромочные кукурузные фрезы Эскиз с основными размерами Обозначение Комплектующие T4B0

Фрезерный инструмент Iscar с твердосплавными режущими пластинами Длиннокромочные кукурузные фрезы Эскиз с основными размерами Обозначение Комплектующие T4B0 LINE T490 CAP-13FT Extension Units for Modular Extended Flute Shell Mills D n Обозначение Designation D ap Flute Z SS jD T490 CAP-D50-24-2-20-13FT 50.00 24.00 2 4 20 0.212 SR 34-535-SN T490 CAP-D50-36-2-20-13FT 50.00 36.00 2 6 20 0.322 SR 34-535-SN T490 CAP-D63-24-3-20-13FT 63.00 24.00 3 6 20 0.335 SR 34-535-SN T490 CAP-D63-24-4-20-13FT 63.00 24.00 4 8 20 0.338 SR 34-535-SN SR M6X6 DIN916 T490 CAP-D63-36-3-20-13FT 63.00 36.00 3 9 20 0.510 SR 34-535-SN T490 CAP-D63-36-4-20-13FT 63.00 36.00 4 12 20 0.497 SR 34-535-SN SR M6X6 DIN916 T490 CAP-D80-24-4-25-13FT 80.00 24.00 4 8 25 0.588 SR 34-535-SN SR M6X8 DIN916 T490 CAP-D80-24-5-25-13FT 80.00 24.00 5 10 25 0.578 SR 34-535-SN T490 CAP-D80-36-4-25-13FT 80.00 36.00 4 12 25 0.884 SR 34-535-SN SR M6X8 DIN916 For inserts, see pages: T490 LNAR (410) T490 LNMT 1306PNTR-FW (410) T490 LNMT/LNHT 1306 (409) Modular Extended Flute Assembly Assembly screw Shell Base Unit Extension 1 Extension 2 D ap L Zeff Z Assembly Screw 47 66.5 8 SR M12x50 DIN912 T490 CAP-D50-24-2-20-13FT "50” 71 90 12 SR M12x70 DIN912 T490 SM-D50-47-2-27-13FT T490 CAP-D50-36-2-20-13FT 50 83 102 2 14 SR M12x80 DIN912 T490 CAP-D50-24-2-20-13FT T490 CAP-D50-24-2-20-13FT 50 94 113 16 SR M12x100 DIN912 T490 CAP-D50-24-2-20-13FT T490 CAP-D50-36-2-20-13FT 50 106 125 18 SR M12x110 DIN912 59 80 15 SR M12x60 DIN912 T490 CAP-D63-24-3-20-13FT "63" 82 103 21 SR M12x80 DIN912 T490 SM-D63-59-3-27-13FT T490 CAP-D63-36-3-20-13FT 63 94 115 3 24 SR M12x100 DIN912 T490 CAP-D63-24-3-20-13FT T490 CAP-D63-24-3-20-13FT 63 106 127 27 SR M12x110 DIN912 T490 CAP-D63-24-3-20-13FT T490 CAP-D63-36-3-20-13FT 63 117 138 30 SR M12x120 DIN912 ap/ae Application Range for 50 mm Modular Extended Flute Cutters ap/ae Application Range for 63 mm Modular Extended Flute Cutters Depth of Cut mm ap 105' 83 70 47 35 B T490 SM-D50-47-3-27-13FT T490 CAP-D50-36-2-20-13FT T490 CAP-D50-24-2-20-13FT T490 SM-D50-47-3-27-13FT T490 CAP-D50-36-2-20-13FT T490 SM-D50-47-2-27-13FT T490 CAP-D50-24-2-20-13FT T490 SM-D50-47-2-27-13FT Depth of Cut mm ap 11 90 T490 SM-D63-59-3-27-13FT T490 CAP-D63-36-3-20-13FT T490 CAP-D63-24-3-20-13FT l l T490 SM-D63-59-3-27-13FT T490 CAP-D63-36-3-20-13FT T490 SM-D63-59-3-27-13FT T490 CAP-D63-24-3-20-13FT T490 SM-D63-59-3-27-13FT 50 Width of Cut mm Width of Cut mm ap/ae Application Range for 80 mm Modular Extended Flute Cutters Workpiece: Alloy Steel Depth of Cut mm ap 125' 105' 93 70 40 Wl T490 SM-D80-70-4-32-13FT T490 CAP-D80-36-4-25-13FT T490 CAP-D80-24-4-25-13FT r l T490 SM-D80-70-4-32-13FT T490 CAP-D80-36-4-25-13FT HT490 SM-D80-70-4-32-13FT T490 CAP-D80-24-4-25-13FT HT490 SM-D80-70-4-32-13FT 50 Width of Cut mm Member IMC Group kSSII t 75 ae ae 10 14 15 20 25 63 8 10 15 18 25 ae 12 15 20 25 EXTENDED FLUTE CUTTERS
