Hoffmann Group 47 Taali ta make yau better Radio transmission The Bobe system allows wireless transmission of measured data to the PC at the press of a button. Note: When ordering the transmitter and receiver please specify the required frequency. Frequencies available: 433.920 MHz 434.075 MHz 434.600 MHz 434.700 MHz 868.300 MHz 868.6625 MHz 869.2125 MHz 869.2750 MHz 869.3625 MHz 869.750 MHz 869.800 MHz 869.9250 MHz Transmitter Transmitters without external antennas. Range 10 -15 m. Very small size. Size suffix E: With data button on the transmitter. Note: Other transmitters for other measuring tools and measuring devices from GARANT, Mahr, Mitutoyo, Kroplin, Tesa, Sylvac, etc. are available on request. Receiver V' Type SI S2 S4E S6 she S16E I i 49 8966 (271.26) (299.97) (323.73) (323.73) (323.73) (323.73) Suitable for: Mitutoyo calipers, dial indicators Mitutoyo micrometers, Kroplin external / internal sensors (6-pin) Mahr EX series Sylvac Opto RS232 Mitutoyo IP calipers Mitutoyo IP micrometers Buzzer and LEDs for confirmation of receipt at the receiver. A maximum of 99 transmitters can be received. 498975 - Multi-receiver for various radio systems. Signals can be received from measuring tools with inbuilt transmitters such as i-wi (Mahr) or Bluetooth Sylvac. Supplied with: USB cable. i498 965 Receiver / USB keyboard interface (279.18) i 49 8975 Multi-receiver / USB keyboard interface (371.25) 498975 USB stick for receiving the i-wi radio system for wireless transmission of measurement data from the measuring instrument to the PC. Type STICK i-wi radio receiver 132.66 E=i£5gp.g= Manufacturer-neutral radio transmission system HF receiver reception of up to 99 addressed transmitters from any manufacturers. HF transmitter Depending on the manufacturer, various transmitters are available. There are securely mounted by cable externally to the data output of the measuring device. 498966 498914 Suitable for all popular manufacturers. 246
