STESA IMICRO internal micrometer DIN 863 0 45 Version Analogue 3-point internal micrometer for high-precision measurement of bores, even at large depths (can be extended with up to three extensions). Self-centring and self-aligning. Individual internal micrometer to Abbe's principle (no first order tilt error). 42 8800 Size 3,5-4 - 10-12 - Anvils of hardened steel (HV30-770). 42 8800 Size 11-14- 90-100 - Anvils titanium nitride (TIN) coated (HV5-2300). 42 8800 Size 100-125 - 275-300- Anvils of titanium carbide (HV5-1300). Supplied with 42 8800 Size 200-225 - 275-300- Extension 150 mm No. 428802 size 5/150, supplied in a wooden box. Optional extras 42 8800- Setting rings No.484030, Extensions No. 428802. Note 42 8800- Centring devices for large measurement depths on request. Measuring range mm 3,5-4 4-4,5 4,5-5,5 5,5-6,5 6-8 8-10 10-12 11-14 14-17 17-20
