Steel wad punch 0 Version Strong, forged design, special tough varnish; taper section (cutting part) bright metal. Slight internal taper for releasing the cut pieces. Application For punching or manufacturing gaskets and gasket rings of rubber, leather, felt, plastic, cork, fabric or similar materials. Note Use an underlay of wood, leather etc. when punching to avoid damage. For hole 0 mm 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 S 83 2000 Steel wad punch For hole 0 mm 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 is 83 2000 Steel wad punch For hole 0 mm 34 35 36 38 40 42 44 45 46 48 50 55 60 65 70 83 2000 Steel wad punch Steel wad punch set Type 3-19R 2-20R 2-30 2-30K y Q3 im n Steel wad s 83 2010 punchset Supplied with Steel wad punch 0 9x size 3-19 mm (2 mm increments) 19x size 2-20 mm (1 mm increments) 15x size 2-30 mm (2 mm increments) 24x size 2-20 mm (1 mm increments) size 22-30 (2 mm increments) Packaging tool roll tool roll tool roll case Wad punch set in a case Version Application 2-component holder (up to size 3-20) with pistol handle with exchangeable precision ground punch cutters. For the production of gaskets two punch cutters of different 0 are inserted together in the holder. For punching or manufacturing discs / rings in one operation. For rubber, leather, felt, plastic, cork, fabric or similar materials. Note Use an underlay of wood, leather etc. when punching. The following combinations are not possible 20 (inner) with 22 (outer); 30 (inner) with 32 (outer); 40 (inner) with 42 (outer); 50 (inner) with 52 (outer). Punched diameter range 3-20 3-30 2-50 2-60 Wad punch i 83 2100 set complete in a case Supplied with 1 x each punch cutter 0 Available combinations of inner / outer punches outer (mm) Container lengthxwidthxheight (mm) Size 3; 4; 6; 8; 10; 12 14; 16; 18; 20 mm 3-10 inner with 12-20 outer plastic 140x100x40 Size 3; 4; 6; 8; 10; 12; 14; 16; 18; 20; 22; 24; 26; 28; 30 mm 1 circle cutter for 0 55-330 mm (with centring pin) 3-10 inner with 12-30 outer 12-20 inner with 22-30 outer plastic 275x205x50 Size 2; 3; 4; 5; 6; 7; 8; 9; 10; 12; 14; 16; 18; 20; 22; 24; 26; 28; 30; 32; 34; 36; 38; 40 42; 44; 46; 48; 50 mm (with centring pin) 2-10 inner with 12-50 outer 12-20 inner with 22-50 outer 22-30 inner with 32-50 outer 32-40 inner with 42-50 outer plastic 265x200x50 Size 2; 3; 4; 5; 6; 7; 8; 9; 10; 12; 14; 16; 18; 20; 22; 24; 26; 28; 30; 32; 34; 36; 38 40; 42; 44; 46; 48; 50; 52; 54; 56; 58; 60 mm 1 circle cutter for 0 55-420 mm (with centring pin) 2-10 inner with 12-60 outer 12-20 inner with 22-60 outer 22-30 inner with 32-60 outer 32-40 inner with 42-60 outer 42-50 inner with 52-60 outer sheet metal approx. 360 x 315 x 55 Spare wad punch cutter For hole 0 mm 2 3 4 5 6 7 8 9 10 83 2110 Spare wad punch cutter For hole 0 mm 12 14 16 18 20 22 24 26 28 832110 Spare wad punch cutter For hole 0 mm 30 32 34 36 38 40 42 44 46 832110 Spare wad punch cutter For hole 0 mm 48 50 52 54 56 58 60 83 2110 Spare wad punch cutter 1408 Main catalogue Hoffmann Group 46
