DRILLING CARBIDE N066 DRILLING (SOLID CARBIDE) MQS WSTAR DRILLS Internal Coolant Internal Coolant DC (mm) a Hole Depth Stock Order Number Dimensions (mm) Type DP3020 LCF X i OAL u. DCON 1R 9 3 MQS1520X3DB 81.1 83.1 142.1 139 3.1 16 1 5 1520X5DB 112.1 115.1 174.1 171 3.1 16 1 15.3 3 1530X3DB 81.2 83.2 142.2 139 3.2 16 1 5 1530X5DB 112.2 115.2 174.2 171 3.2 16 1 15.4 3 1540X3DB 81.2 83.2 142.2 139 3.2 16 1 5 1540X5DB 112.2 115.2 174.2 171 3.2 16 1 3 1550X3DB 81.2 83.2 142.2 139 3.2 16 1 15.5 5 1550X5DB 112.2 115.2 174.2 171 3.2 16 1 r8 1550X8DB 174.2 184.2 244.2 241 3.2 16 15.6 3 1560X3DB 83.2 83.2 142.2 139 3.2 16 1 5 1560X5DB 115.2 115.2 174.2 171 3.2 16 1 15.7 3 1570X3DB 83.3 83.3 142.3 139 3.3 16 1 5 1570X5DB 115.3 115.3 174.3 171 3.3 16 1 15.8 3 1580X3DB 83.3 83.3 142.3 139 3.3 16 1 5 1580X5DB 115.3 115.3 174.3 171 3.3 16 1 15.9 3 1590X3DB 83.3 83.3 142.3 139 3.3 16 1 5 1590X5DB 115.3 115.3 174.3 171 3.3 16 1 3 1600X3DB 83.3 83.3 142.3 139 3.3 16 1 16.0 5 1600X5DB 115.3 115.3 174.3 171 3.3 16 1 (m 8 1600X8DB 179.3 184.3 244.3 241 3.3 16 16.1 3 1610X3DB 86.3 89.3 148.3 145 3.3 17 1 5 1610X5DB 119.3 123.3 182.3 179 3.3 17 1 16.2 3 1620X3DB 86.4 89.4 148.4 145 3.4 17 1 5 1620X5DB 119.4 123.4 182.4 179 3.4 17 1 16.3 3 1630X3DB 86.4 89.4 148.4 145 3.4 17 1 5 1630X5DB 119.4 123.4 182.4 179 3.4 17 1 16.4 3 1640X3DB 86.4 89.4 148.4 145 3.4 17 1 5 1640X5DB 119.4 123.4 182.4 179 3.4 17 1 16.5 3 1650X3DB 86.4 89.4 148.4 145 3.4 17 1 5 1650X5DB 119.4 123.4 182.4 179 3.4 17 1 16.6 3 1660X3DB 88.4 89.4 148.4 145 3.4 17 1 5 1660X5DB 122.4 123.4 182.4 179 3.4 17 1 16.7 3 1670X3DB 88.5 89.5 148.5 145 3.5 17 1 5 1670X5DB 122.5 123.5 182.5 179 3.5 17 1 16.8 3 1680X3DB 88.5 89.5 148.5 145 3.5 17 1 5 1680X5DB 122.5 123.5 182.5 179 3.5 17 1 16.9 3 1690X3DB 88.5 89.5 148.5 145 3.5 17 1 5 1690X5DB 122.5 123.5 182.5 179 3.5 17 1 17.0 3 1700X3DB 88.5 89.5 148.5 145 3.5 17 1 5 1700X5DB 122.5 123.5 182.5 179 3.5 17 1 17.1 3 1710X3DB 91.5 93.5 152.5 149 3.5 18 1 5 1710X5DB 126.5 129.5 188.5 185 3.5 18 1 17.2 3 1720X3DB 91.6 93.6 152.6 149 3.6 18 1 5 1720X5DB 126.6 129.6 188.6 185 3.6 18 1 17.3 3 1730X3DB 91.6 93.6 152.6 149 3.6 18 1 5 1730X5DB 126.6 129.6 188.6 185 3.6 18 1 17.4 3 1740X3DB 91.6 93.6 152.6 149 3.6 18 1 5 1740X5DB 126.6 129.6 188.6 185 3.6 18 1 17.5 3 1750X3DB 91.6 93.6 152.6 149 3.6 18 1 5 1750X5DB 126.6 129.6 188.6 185 3.6 18 1 DC (mm) a Hole Depth Stock Order Number Dimensions (mm) Type DP3020 LCF X i OAL u. DCON 17.6 3 MQS1760X3DB 93.6 93.6 152.6 149 3.6 18 1 5 1760X5DB 129.6 129.6 188.6 185 3.6 18 1 17.7 3 1770X3DB 93.7 93.7 152.7 149 3.7 18 1 5 1770X5DB 129.7 129.7 188.7 185 3.7 18 1 17.8 3 1780X3DB 93.7 93.7 152.7 149 3.7 18 1 5 1780X5DB 129.7 129.7 188.7 185 3.7 18 1 17.9 3 1790X3DB 93.7 93.7 152.7 149 3.7 18 1 5 1790X5DB 129.7 129.7 188.7 185 3.7 18 1 18.0 3 1800X3DB 93.7 93.7 152.7 149 3.7 18 1 5 1800X5DB 129.7 129.7 188.7 185 3.7 18 1 18.1 3 1810X3DB 96.7 99.7 160.7 157 3.7 19 1 5 1810X5DB 133.7 137.7 198.7 195 3.7 19 1 18.2 3 1820X3DB 96.8 99.8 160.8 157 3.8 19 1 5 1820X5DB 133.8 137.8 198.8 195 3.8 19 1 18.3 3 1830X3DB 96.8 99.8 160.8 157 3.8 19 1 5 1830X5DB 133.8 137.8 198.8 195 3.8 19 1 18.4 3 1840X3DB 96.8 99.8 160.8 157 3.8 19 1 5 1840X5DB 133.8 137.8 198.8 195 3.8 19 1 18.5 3 1850X3DB 96.8 99.8 160.8 157 3.8 19 1 5 1850X5DB 133.8 137.8 198.8 195 3.8 19 1 18.6 3 1860X3DB 98.9 99.9 160.9 157 3.9 19 1 5 1860X5DB 136.9 137.9 198.9 195 3.9 19 1 18.7 3 1870X3DB 98.9 99.9 160.9 157 3.9 19 1 5 1870X5DB 136.9 137.9 198.9 195 3.9 19 1 18.8 3 1880X3DB 98.9 99.9 160.9 157 3.9 19 1 5 1880X5DB 136.9 137.9 198.9 195 3.9 19 1 18.9 3 1890X3DB 98.9 99.9 160.9 157 3.9 19 1 5 1890X5DB 136.9 137.9 198.9 195 3.9 19 1 19.0 3 1900X3DB 98.9 99.9 160.9 157 3.9 19 1 5 1900X5DB 136.9 137.9 198.9 195 3.9 19 1 19.1 3 1910X3DB 102.0 104.0 165.0 161 4.0 20 1 5 1910X5DB 141.0 144.0 205.0 201 4.0 20 1 19.2 3 1920X3DB 102.0 104.0 165.0 161 4.0 20 1 5 1920X5DB 141.0 144.0 205.0 201 4.0 20 1 19.3 3 1930X3DB 102.0 104.0 165.0 161 4.0 20 1 5 1930X5DB 141.0 144.0 205.0 201 4.0 20 1 19.4 3 1940X3DB 102.0 104.0 165.0 161 4.0 20 1 5 1940X5DB 141.0 144.0 205.0 201 4.0 20 1 19.5 3 1950X3DB 102.0 104.0 165.0 161 4.0 20 1 5 1950X5DB 141.0 144.0 205.0 201 4.0 20 1 19.6 3 1960X3DB 104.1 104.1 165.1 161 4.1 20 1 5 1960X5DB 144.1 144.1 205.1 201 4.1 20 1 19.7 3 1970X3DB 104.1 104.1 165.1 161 4.1 20 1 5 1970X5DB 144.1 144.1 205.1 201 4.1 20 1 19.8 3 1980X3DB 104.1 104.1 165.1 161 4.1 20 1 5 1980X5DB 144.1 144.1 205.1 201 4.1 20 1 19.9 3 1990X3DB 104.1 104.1 165.1 161 4.1 20 1 5 1990X5DB 144.1 144.1 205.1 201 4.1 20 1 20.0 3 2000X3DB 104.1 104.1 165.1 161 4.1 20 1 5 2000X5DB 144.1 144.1 205.1 201 4.1 20 1 (Note) Please contact us for any geometry that is not in this catalogue (e.g. different diameter and length). Inventory maintained in Japan. Non stock produced to order only.
