Wave Repeater Mill WRX (-F) Type Body (Shell Type “F”) Body (Shell Type “F”) Cat. No. Stock Depth of cut (doc) Dimensions (mm) Размеры указаны в мм No. of teeth No. of rows Effec- tive teeth 0D 0d1 0d2 a b l1 l l WRX2040RH18F16 18 40 16 9 8,4 5,6 50 39 18 10 2 5 WRX2040RH36F16 36 40 16 9 8,4 5,6 55 44 18 16 4 4 WRX2050RH18F22 18 50 22 11 10,4 6,3 50 36 20 10 2 5 WRX2050RH36F22 36 50 22 11 10,4 6,3 55 41,5 20 16 4 4 Cat. No. o ot OT Depth of Cut (doc) Dimensions (mm) Размеры указаны в мм No. of teeth No. of rows Effec- tive teeth 0D 0d1 0d2 a b l1 l l WRX3050RH27F22 27 50 22 11 10 6,3 50 36 20 8 2 4 WRX3050RH53F22 53 50 22 11 10 6,3 70 56 20 12 4 3 WRX3063RH27F27 27 63 27 13,5 12 7 70 34 2 10 2 5 WRX3063RH53F27 53 63 27 13,5 12 7 70 54 2 16 4 4 WRX3080RH27F32 27 80 32 17 14 8 50 30 2 12 2 6 WRX3080RH53F32 53 80 32 17 14 8 85 63 2 20 4 5 WRX3100RH27F40 27 100 40 21 16 9,5 85 40 30 14 2 7 WRX3100RH53F40 53 100 40 21 16 9,5 85 59 30 24 4 6 Inserts (Same as for Wavemill WEX 2000 Type) Application High Speed / Light cut General Purpose Roughing Cat. No. AXMT 123504 PEER-G 123508 PEER-G 123512 PEER-G AXMT 123504 PEER-H 123508 PEER-H 123512 PEER-H AXMT 123504 PEER-E 123508 PEER-E 123512 PEER-E AXMT 123508 PEER-EH AXET 123502 PEFR-S 123504 PEFR-S 123508 PEFR-S Coated Carbide 0 M3 a a - Unable to produce L - Low cutting force G - General type H - Strong cutting edge E - For stainless steel EH- Strong edge for stainless steel S - For aluminium I Spare Parts Запасные части Sumitomo и комплектующие Screw Wrench /" Applicable Endmill BFTX 0306 IP TRDR 08 IP 2,0 WRX 2 RH F BFTX 0409 IP TRDR 15 IP 3,0 WRX 3 RH F Inserts (Same as for Wavemill WEX 3000 Type) J i CM 17 54 Application High Speed / Light cut General Purpose Roughing Cat. No. AXMT 170508 PEER-L AXMT 170504 170508 170512 170516 170520 170530 AXMT 170508 PEER-H 170512 PEER-H AXMT AXMT AXET PEER-G PEER-G PEER-G PEER-G PEER-G PEER-G 170504 170508 170512 170516 170520 170530 PEER-E PEER-E PEER-E PEER-E PEER-E PEER-E 170508 PEER-EH 170502 PEFR-S 170504 PEFR-S 170508 PEFR-S Coated Carbide 0 Cutter body modification is required. Identification Details WRX 20 25 R H a 51 Insert Size Tool 0D Cutting Direction Inner coolant 27 Cutting Edge Length a a 08 0,4 0, 1,2 1,6 2,0 3.0 0,8 1,2 0,4 0,8 1,2 1,6 2.0 3,0 0, 0,2 0,4 0, W 25 Arbor Type Arbor Diameter E - Straight Shank W F Weldon Shank Shell Type 11° 11 Carbide DLC Carbide DLC Radius Radius G39 Milling Cutters
