Technical Information for PCD Endmill Longer tool life and good surface finishes PCD Endmill Longer tool life and good surface roughness Reducing burrs at non-ferrous metals machining 1000 type: Ultra finishing for non-ferrous metals 2000 type: Optimal for aluminum alloy, carbon steel, graphite and reinforced Plastic machining O PCD endmill code system Endmill PDE: PCD Endmill No. of Flute 2 Flutes Diameter 08.0 O Recommended cutting conditions Workpiece vc (m/min) n (min-1) fz (mm/t) Aluminum alloy, Copper 30-300 2,000-12,000 0.02-0.07 Reinforced plastic 35-300 2,800-16,000 0.04-0.12 Carbon steel, Graphite 10-100 5,300-16,000 0.04-0.2 Special endmill order form 0D I Fig.1 0dJ 0dJ 0d Fig.2 Designation Fig. No. of Flute Dimension (mm) 0D 0d r a 1 L PDES .L x Depending on customer requests, we can make special Endmill Endmills 114 2
