WORKSHOP DRILL BITS taps AND DIES DIES 221 SPLIT DIES 0- m H W ISO 261 DIN ISO 261 NF E 03-013 ISO metric RH thread. Chrome-vanadium HSS hardened to 62 64 HRc (234 daN mm ). Tapered adjusting screw. F NW mm e mm P mm 0 mm D q 221.3X50 3 8 35 050 254 28 221.4X70 4 8 35 070 254 27 221.5X80 5 8 35 080 254 29 221.6X100 6 9 35 100 254 29 221.7X100 7 9 35 125 254 30 221.8X125 8 9 35 125 254 30 221.9X125 9 9 35 125 254 30 221.10X150 10 13 60 150 381 79 221.12X175 12 13 60 175 381 89 221.14X200 14 13 60 200 381 79 221.16X200 16 13 60 200 381 74 221.18X250 18 15 80 250 381 75 P- r 90 xL -r- j 1 r K -t i THREADING AND TAPPING TOOL SETS tap and die sets For threads 0 3-12 mm and 03-18 mm. Sets 221.227SJ1 and 221.227SJ2 include cobalt-steel taps 227.S. F I mm x O v V 0 mm D kq 221.227J1 470 x 195 x 53 9 x 2 9 2 2 M3-M12 31 221.227SJ1 470 x 195 x 53 9 x 2 9 2 2 M3-M12 31 221.227J2 540 x 284 x 58 12 x 2 12 2 3 M3-M18 57 221.227SJ2 540 x 284 x 58 12 x 2 12 2 3 M3-M18 57 221.227J1 221.227J2 tap and drill-bit sets Each set includes 3 taps (taper second bottoming) and equivalent drill bit 222A.T. Set 227.SJ2A includes cobalt-steel taps 227.S. F I x 0 0 f D mm kq 227.J2A 172 x 105 x 57 3 x 7 M3mM12 25-33-42-5-68-85-102 11 227.SJ2A 172 x 105 x 57 3 x 7 M3mM12 25-33-42-5-68-85-102 11 catalogue FACOM F05 453
