DRILLING CARBIDE N256 CVD DIAMOND COATED DRILLS OCBSS Drill for hard brittle materials Q (DC) DCS0.07 - N Ncr-'erous Metal 0.05DC0.2 Order Number DC LCF OAL LF PL DCON O to g P Short Delivery 1 DCBSSD0005 0.05 (0.5) - 38 - 3 1 O D0006 0.06 (0.6) - 38 - 3 1 D0007 0.07 0.704 38.004 38 0.004 3 2 O D0008 0.08 0.805 38.005 38 0.005 3 2 o 0009 0.09 0.906 38.006 38 0.006 3 2 o 0010 0.10 1.01 38.01 38 0.01 3 2 0011 0.11 1.21 38.01 38 0.01 3 2 D0012 0.12 1.41 38.01 38 0.01 3 2 D0013 0.13 1.51 38.01 38 0.01 3 2 D0014 0.14 1.51 38.01 38 0.01 3 2 D0015 0.15 1.51 38.01 38 0.01 3 2 D0016 0.16 1.51 38.01 38 0.01 3 2 0017 0.17 1.51 38.01 38 0.01 3 2 D0018 0.18 1.51 38.01 38 0.01 3 2 0019 0.19 1.51 38.01 38 0.01 3 2 D0020 0.20 2.01 38.01 38 0.01 3 3 D0021 0.21 2.01 38.01 38 0.01 3 3 o 0022 0.22 2.01 38.01 38 0.01 3 3 0023 0.23 2.01 38.01 38 0.01 3 3 o D0024 0.24 2.01 38.01 38 0.01 3 3 o D0025 0.25 2.52 38.02 38 0.02 3 3 D0026 0.26 2.52 38.02 38 0.02 3 3 o D0027 0.27 2.52 38.02 38 0.02 3 3 o D0028 0.28 2.52 38.02 38 0.02 3 3 o 0029 0.29 2.52 38.02 38 0.02 3 3 o 0030 0.30 3.02 38.02 38 0.02 3 3 D0031 0.31 3.02 38.02 38 0.02 3 3 o 0032 0.32 3.02 38.02 38 0.02 3 3 o D0033 0.33 3.02 38.02 38 0.02 3 3 o D0034 0.34 3.52 38.02 38 0.02 3 3 o 0035 0.35 3.52 38.02 38 0.02 3 3 0036 0.36 3.52 38.02 38 0.02 3 3 o For machining materials such as sintered ceramics and quartz glass that cannot be machined with conventional drills. i H EE) 0 -0.009 0 -0.006 0.2DC3 0 -0.014 0 -0.006 LF LF OAL LF OAL Typel Type2 Type3 Unit mm Order Number DC LCF OAL LF PL DCON U s V) 13 1 Short 1 Delivery 1 DCBSSD0040 0.40 4.02 38.02 38 0.02 3 3 0045 0.45 4.03 38.03 38 0.03 3 3 O 0050 0.50 4.03 38.03 38 0.03 3 3 D0055 0.55 4.53 38.03 38 0.03 3 3 O D0060 0.60 5.04 38.04 38 0.04 3 3 D0070 0.70 5.04 38.04 38 0.04 3 3 D0080 0.80 6.05 38.05 38 0.05 3 3 0085 0.85 6.05 38.05 38 0.05 3 3 o 0090 0.90 6.06 38.06 38 0.06 3 3 0100 1.00 8.1 38.1 38 0.1 3 3 D0110 1.10 8.1 38.1 38 0.1 3 3 D0120 1.20 8.1 38.1 38 0.1 3 3 D0130 1.30 8.1 38.1 38 0.1 3 3 D0140 1.40 8.1 38.1 38 0.1 3 3 D0150 1.50 10.1 38.1 38 0.1 3 3 D0160 1.60 10.1 38.1 38 0.1 3 3 D0170 1.70 10.1 38.1 38 0.1 3 3 D0180 1.80 10.1 38.1 38 0.1 3 3 D0190 1.90 10.1 38.1 38 0.1 3 3 D0200 2.00 12.1 38.1 38 0.1 3 3 D0210 2.10 12.1 38.1 38 0.1 3 3 o 0220 2.20 12.1 38.1 38 0.1 3 3 o 0230 2.30 12.1 38.1 38 0.1 3 3 D0240 2.40 12.2 38.2 38 0.2 3 3 o D0250 2.50 12.2 38.2 38 0.2 3 3 D0260 2.60 12.2 38.2 38 0.2 3 3 D0270 2.70 12.2 38.2 38 0.2 3 3 0280 2.80 12.2 38.2 38 0.2 3 3 0290 2.90 12.2 38.2 38 0.2 3 3 D0300 3.00 12.2 38.2 38 0.2 3 3 o (Note 1) Stock mark (produced on order products) shows the basic sizes. Consult us If different diameters and flute lengths. (Note 2) Drills with mark can be delivered within 1-2 weeks. For the delivery of other drills contact Mitsubishi Materials. (Note 3) DC0.05 0.06 are special shape specifications without groove. LCF is the neck lengths instead of the flute lengths. Inventory maintained in Japan. Non stock produced to order only.
