Q. CL Geometry Stock Coated Cermet Carbide CBN Seat Size CW 2 Order Number VP10RT VP20RT MY5015 NX2525 RT9010 RT9020 BC8110 MB8025 Cutting Width Tolerance RER/L CDX L LE GY2M0200D020R05-GM D 2.00 ±0.03 0.2 19.5 20.80 GY2M0200D020L05-GM D 2.00 ±0.03 0.2 19.5 20.80 - GY2M0250E020R05-GM E 2.50 ±0.03 0.2 19.5 20.825 GY2M0250E020L05-GM E 2.50 ±0.03 0.2 19.5 20.825 GY2M0300F030R05-GM F 3.00 ±0.03 0.3 19.5 20.85 GY2M0300F030L05-GM F 3.00 ±0.03 0.3 19.5 20.85 GY2M0400G030R05-GM G 4.00 ±0.04 0.3 24.5 25.85 GY2M0400G030L05-GM G 4.00 ±0.04 0.3 24.5 25.85 GY2M0500H040R05-GM H 5.00 ±0.04 0.4 24.5 25.95 GY2M0500H040L05-GM H 5.00 ±0.04 0.4 24.5 25.95 GY1G0200D020N-GFGS D 2.00 ±0.03 0.2 20.70 2.7 GY1G0239E020N-G FGS E 2.39 ±0.03 0.2 - 20.70 2.7 GY1G0250E020N-GFGS E 2.50 ±0.03 0.2 20.70 2.7 GY1G0300F020N-GFGS F 3.00 ±0.03 0.2 20.70 2.7 GY1G0318F020N-GFGS F 3.18 ±0.03 0.2 20.70 2.7 GY1G0400G020N-GFGS G 4.00 ±0.03 0.2 25.65 2.7 GY1G0475H020N-GFGS H 4.75 ±0.03 0.2 25.65 2.7 GY1G0500H020N-GFGS H 5.00 ±0.03 0.2 25.65 2.7 G Y1G0600J020N -G FG S J 6.00 ±0.03 0.2 25.65 2.7 GY2G0200D020N-MF D 2.00 ±0.02 0.2 19.5 21.05 1GY2G0224D015N-MF D 2.24 ±0.02 0.15 19.8 21.05 GY2G0239E020N-MF E 2.39 ±0.02 0.2 19.2 21.05 - GY2G0250E020N-MF E 2.50 ±0.02 0.2 19.4 21.05 1GY2G0274E020N-MF E 2.74 ±0.02 0.2 19.7 21.05 GY2G0300F020N-MF F 3.00 ±0.02 0.2 19.5 21.05 GY2G0300F040N-MF F 3.00 ±0.02 0.4 19.3 21.05 GY2G0318F020N-MF F 3.18 ±0.02 0.2 19.5 21.05 GY2G0318F040N-MF F 3.18 ±0.02 0.4 19.3 21.05 1GY2G0324F020N-MF F 3.24 ±0.02 0.2 19.5 21.05 GY2G0400G020N-MF G 4.00 ±0.02 0.2 24.9 25.95 GY2G0400G040N-MF G 4.00 ±0.02 0.4 24.7 25.95 GY2G0400G080N-MF G 4.00 ±0.02 0.8 24.3 25.95 - 1GY2G0424G020N-MF G 4.24 ±0.02 0.2 24.9 25.95 GY2G0475H020IM-MF H 4.75 ±0.02 0.2 24.4 25.95 GY2G0475H040IM-MF H 4.75 ±0.02 0.4 24.2 25.95 GY2G0475H080N-MF H 4.75 ±0.02 0.8 23.8 25.95 GY2G0500H020N-MF H 5.00 ±0.02 0.2 24.4 25.95 GY2G0500H040IM-MF H 5.00 ±0.02 0.4 24.2 25.95 GY2G0500H080IM-MF H 5.00 ±0.02 0.8 23.8 25.95 1GY2G0524H020I\I-MF H 5.24 ±0.02 0.2 24.4 25.95 GY2G0600J020N-MF J 6.00 ±0.02 0.2 24.4 25.95 GY2G0600J040N-MF J 6.00 ±0.02 0.4 24.2 25.95 - GY2G0600J080N-MF J 6.00 ±0.02 0.8 23.8 25.95 1GY2G0631 J020N-MF J 6.31 ±0.02 0.2 24.4 25.95 GY2G0635J020N-MF J 6.35 ±0.02 0.2 24.4 25.95 GY2G0635J040N-MF J 6.35 ±0.02 0.4 24.2 25.95 GY2G0635J080N-MF J 6.35 ±0.02 0.8 23.8 25.95 - Dimensions (mm) R/L05-GM Breaker REL±0.05 fc o RER±0.05 PSIRR 5" CDX L±0.1 Right hand insert shown. Flat Top (For hardened steel) LE > 5 o . Lan> L±0.1 MF Breaker (Finishing) ) C '> l (J TO C o REL±0.05 ul RER±0.05 CDX 1 Circlip corresponding width of cut F011 GROOVING / CUTTING OFF
