DRILLING DRILLING (SOLID CARBIDE) CARBIDE IfMS WSTAR DRILLS ONew grade DP7020 unique coolant system special fine margin. Long tool life and high efficiency drilling for stainless steel. DC3 3DC6 6DC10 O A Cl O IA O CM VI o Q V 03 0 -0.014 0 -0.018 0 -0.022 0 -0.027 0 -0.033 0 -0.008 0 -0.009 0 -0.011 0 -0.013 M Stainless Steel JLZJ ten im (Note) MMS drills are suitable for use with shrink fit holders. Internal Coolant of viewing. This does not have any effect on the performance of the drill. Internal Coolant DC (mm) a Hole Depth Stock Order Number Dimensions (mm) DP7020 LCF X i OAL u. DCON 3.0 3 MMS0300X3DB 21.5 23.5 70.5 70 0.5 6 5 0300X5DB 28.5 31.5 78.5 78 0.5 6 3.1 3 0310X3DB 21.6 23.6 70.6 70 0.6 6 5 0310X5DB 28.6 31.6 78.6 78 0.6 6 3.2 3 0320X3DB 21.6 23.6 70.6 70 0.6 6 5 0320X5DB 28.6 31.6 78.6 78 0.6 6 3.3 3 0330X3DB 21.6 23.6 70.6 70 0.6 6 5 0330X5DB 28.6 31.6 78.6 78 0.6 6 3.4 3 0340X3DB 21.6 23.6 70.6 70 0.6 6 5 0340X5DB 28.6 31.6 78.6 78 0.6 6 3.5 3 0350X3DB 21.6 23.6 70.6 70 0.6 6 5 0350X5DB 28.6 31.6 78.6 78 0.6 6 3.6 3 0360X3DB 22.7 23.7 70.7 70 0.7 6 5 0360X5DB 30.7 31.7 78.7 78 0.7 6 3.7 3 0370X3DB 22.7 23.7 70.7 70 0.7 6 5 0370X5DB 30.7 31.7 78.7 78 0.7 6 3.8 3 0380X3DB 22.7 23.7 70.7 70 0.7 6 5 0380X5DB 30.7 31.7 78.7 78 0.7 6 3.9 3 0390X3DB 22.7 23.7 70.7 70 0.7 6 5 0390X5DB 30.7 31.7 78.7 78 0.7 6 4.0 3 0400X3DB 22.7 23.7 70.7 70 0.7 6 5 0400X5DB 30.7 31.7 78.7 78 0.7 6 4.1 3 0410X3DB 24.7 26.7 73.7 73 0.7 6 5 0410X5DB 33.7 35.7 82.7 82 0.7 6 4.2 3 0420X3DB 24.8 26.8 73.8 73 0.8 6 5 0420X5DB 33.8 35.8 82.8 82 0.8 6 4.3 3 0430X3DB 24.8 26.8 73.8 73 0.8 6 5 0430X5DB 33.8 35.8 82.8 82 0.8 6 4.4 3 0440X3DB 24.8 26.8 73.8 73 0.8 6 5 0440X5DB 33.8 35.8 82.8 82 0.8 6 4.5 3 0450X3DB 24.8 26.8 73.8 73 0.8 6 5 0450X5DB 33.8 35.8 82.8 82 0.8 6 4.6 3 0460X3DB 25.8 28.8 75.8 75 0.8 6 5 0460X5DB 35.8 38.8 85.8 85 0.8 6 4.7 3 0470X3DB 25.9 28.9 75.9 75 0.9 6 5 0470X5DB 35.9 38.9 85.9 85 0.9 6 4.8 3 0480X3DB 25.9 28.9 75.9 75 0.9 6 5 0480X5DB 35.9 38.9 85.9 85 0.9 6 (Note) Please contact us for any geometry that is not In this catalogue Inventory maintained in Japan. DC (mm) a Hole Depth Stock Order Number Dimensions (mm) DP7020 LCF X i OAL u. DCON 4.9 3 MMS0490X3DB 25.9 28.9 75.9 75 0.9 6 5 0490X5DB 35.9 38.9 85.9 85 0.9 6 5.0 3 0500X3DB 25.9 28.9 75.9 75 0.9 6 5 0500X5DB 35.9 38.9 85.9 85 0.9 6 5.1 3 0510X3DB 28.9 30.9 81.9 81 0.9 6 5 0510X5DB 39.9 42.9 89.9 89 0.9 6 5.2 3 0520X3DB 28.9 30.9 81.9 81 0.9 6 5 0520X5DB 39.9 42.9 89.9 89 0.9 6 5.3 3 0530X3DB 29.0 31.0 82.0 81 1.0 6 5 0530X5DB 40.0 43.0 90.0 89 1.0 6 5.4 3 0540X3DB 29.0 31.0 82.0 81 1.0 6 5 0540X5DB 40.0 43.0 90.0 89 1.0 6 5.5 3 0550X3DB 29.0 31.0 82.0 81 1.0 6 5 0550X5DB 40.0 43.0 90.0 89 1.0 6 5.6 3 0560X3DB 31.0 31.0 82.0 81 1.0 6 5 0560X5DB 43.0 43.0 90.0 89 1.0 6 5.7 3 0570X3DB 31.0 31.0 82.0 81 1.0 6 5 0570X5DB 43.0 43.0 90.0 89 1.0 6 5.8 3 0580X3DB 31.1 31.1 82.1 81 1.1 6 5 0580X5DB 43.1 43.1 90.1 89 1.1 6 5.9 3 0590X3DB 31.1 31.1 82.1 81 1.1 6 5 0590X5DB 43.1 43.1 90.1 89 1.1 6 6.0 3 0600X3DB 31.1 31.1 82.1 81 1.1 6 5 0600X5DB 43.1 43.1 90.1 89 1.1 6 6.1 3 0610X3DB 34.1 36.1 87.1 86 1.1 8 5 0610X5DB 47.1 49.1 96.1 95 1.1 8 6.2 3 0620X3DB 34.1 36.1 87.1 86 1.1 8 5 0620X5DB 47.1 49.1 96.1 95 1.1 8 6.3 3 0630X3DB 34.1 36.1 87.1 86 1.1 8 5 0630X5DB 47.1 49.1 96.1 95 1.1 8 6.4 3 0640X3DB 34.2 36.2 87.2 86 1.2 8 5 0640X5DB 47.2 49.2 96.2 95 1.2 8 6.5 3 0650X3DB 34.2 36.2 87.2 86 1.2 8 5 0650X5DB 47.2 49.2 96.2 95 1.2 8 6.6 3 0660X3DB 36.2 38.2 91.2 90 1.2 8 5 0660X5DB 50.2 52.2 99.2 98 1.2 8 6.7 3 0670X3DB 36.2 38.2 91.2 90 1.2 8 5 0670X5DB 50.2 52.2 99.2 98 1.2 8 e.g. different diameter and length). N070
