1579 Каталог MITSUBISHI 2020 Режущий инструмент Фрезы Резцы Сверла Пластины Стр.P123

Каталог MITSUBISHI 2020 Режущий инструмент для станков Стр. P123 1579 Lab2u

DC (mm) g Hole Depth VP15TF Order Number Dimensions (mm) Type D l LCF X i OAL LL l i CL DCON 4.1 2 MZE0410SA 8.9 22.7 22.7 55.7 55 0.7 4.1 1 4.1 3 MZE0410MA 13.0 29.7 29.7 63.7 63 0.7 4.1 1 4.2 2 MZE0420SA 9.2 22.8 22.8 55.8 55 0.8 4.2 1 4.2 3 MZE0420MA 13.4 29.8 29.8 63.8 63 0.8 4.2 1 4.3 2 MZE0430SA 9.4 24.8 24.8 58.8 58 0.8 4.3 1 4.3 3 MZE0430MA 13.7 29.8 29.8 63.8 63 0.8 4.3 1 4.4 2 MZE0440SA 9.6 24.8 24.8 58.8 58 0.8 4.4 1 4.4 3 MZE0440MA 14.0 29.8 29.8 63.8 63 0.8 4.4 1 4.5 2 MZE0450SA 9.8 24.8 24.8 58.8 58 0.8 4.5 1 4.5 3 MZE0450MA 14.3 29.8 29.8 63.8 63 0.8 4.5 1 4.6 2 MZE0460SA 10.0 24.8 24.8 58.8 58 0.8 4.6 1 4.6 3 MZE0460MA 14.6 32.8 32.8 68.8 68 0.8 4.6 1 4.7 2 MZE0470SA 10.3 24.9 24.9 58.9 58 0.9 4.7 1 4.7 3 MZE0470MA 15.0 32.9 32.9 68.9 68 0.9 4.7 1 4.8 2 MZE0480SA 10.5 26.9 26.9 62.9 62 0.9 4.8 1 4.8 3 MZE0480MA 15.3 32.9 32.9 68.9 68 0.9 4.8 1 4.9 2 MZE0490SA 10.7 26.9 26.9 62.9 62 0.9 4.9 1 4.9 3 MZE0490MA 15.6 32.9 32.9 68.9 68 0.9 4.9 1 5.0 2 MZE0500SA 10.9 26.9 26.9 62.9 62 0.9 5.0 1 5.0 3 MZE0500MA 15.9 32.9 32.9 68.9 68 0.9 5.0 1 5.1 2 MZE0510SA 11.1 26.9 26.9 62.9 62 0.9 5.1 1 5.1 3 MZE0510MA 16.2 34.9 34.9 72.9 72 0.9 5.1 1 5.2 2 MZE0520SA 11.3 26.9 26.9 62.9 62 0.9 5.2 1 5.2 3 MZE0520MA 16.5 34.9 34.9 72.9 72 0.9 5.2 1 5.3 2 MZE0530SA 11.6 27.0 27.0 63.0 62 1.0 5.3 1 5.3 3 MZE0530MA 16.9 35.0 35.0 73.0 72 1.0 5.3 1 5.4 2 MZE0540SA 11.8 29.0 29.0 67.0 66 1.0 5.4 1 5.4 3 MZE0540MA 17.2 35.0 35.0 73.0 72 1.0 5.4 1 5.5 2 MZE0550SA 12.0 29.0 29.0 67.0 66 1.0 5.5 1 5.5 3 MZE0550MA 17.5 35.0 35.0 73.0 72 1.0 5.5 1 5.6 2 MZE0560SA 12.2 29.0 29.0 67.0 66 1.0 5.6 1 5.6 3 MZE0560MA 17.8 37.0 37.0 75.0 74 1.0 5.6 1 5.7 2 MZE0570SA 12.4 29.0 29.0 67.0 66 1.0 5.7 1 5.7 3 MZE0570MA 18.1 37.0 37.0 75.0 74 1.0 5.7 1 5.8 2 MZE0580SA 12.7 29.1 29.1 67.1 66 1.1 5.8 1 5.8 3 MZE0580MA 18.5 37.1 37.1 75.1 74 1.1 5.8 1 5.9 2 MZE0590SA 12.9 29.1 29.1 67.1 66 1.1 5.9 1 5.9 3 MZE0590MA 18.8 37.1 37.1 75.1 74 1.1 5.9 1 6.0 2 MZE0600SA 13.1 29.1 29.1 67.1 66 1.1 6.0 1 6.0 3 MZE0600MA 19.1 42.1 42.1 82.1 81 1.1 6.0 1 6.1 2 MZE0610SA 13.3 32.1 32.1 71.1 70 1.1 6.1 1 6.1 3 MZE0610MA 19.4 42.1 42.1 82.1 81 1.1 6.1 1 6.2 2 MZE0620SA 13.5 32.1 32.1 71.1 70 1.1 6.2 1 6.2 3 MZE0620MA 19.7 42.1 42.1 82.1 81 1.1 6.2 1 6.3 2 MZE0630SA 13.7 32.1 32.1 71.1 70 1.1 6.3 1 6.3 3 MZE0630MA 20.0 42.1 42.1 82.1 81 1.1 6.3 1 6.4 2 MZE0640SA 14.0 32.2 32.2 71.2 70 1.2 6.4 1 6.4 3 MZE0640MA 20.4 42.2 42.2 82.2 81 1.2 6.4 1 DC (mm) 5 Hole Depth VP15TF Order Number Dimensions (mm) Type 3 l LCF X i OAL LL l i Q. DCON 6.5 2 MZE0650SA 14.2 32.2 32.2 71.2 70 1.2 6.5 1 6.5 3 MZE0650MA 20.7 42.2 42.2 82.2 81 1.2 6.5 1 6.6 2 MZE0660SA 14.4 32.2 32.2 71.2 70 1.2 6.6 1 6.6 3 MZE0660MA 21.0 44.2 44.2 84.2 83 1.2 6.6 1 6.7 2 MZE0670SA 14.6 32.2 32.2 71.2 70 1.2 6.7 1 6.7 3 MZE0670MA 21.3 44.2 44.2 84.2 83 1.2 6.7 1 6.8 2 MZE0680SA 14.8 35.2 35.2 75.2 74 1.2 6.8 1 6.8 3 MZE0680MA 21.6 44.2 44.2 84.2 83 1.2 6.8 1 6.9 2 MZE0690SA 15.1 35.3 35.3 75.3 74 1.3 6.9 1 6.9 3 MZE0690MA 22.0 44.3 44.3 84.3 83 1.3 6.9 1 7.0 2 MZE0700SA 15.3 35.3 35.3 75.3 74 1.3 7.0 1 7.0 3 MZE0700MA 22.3 44.3 44.3 84.3 83 1.3 7.0 1 7.1 2 MZE0710SA 15.5 35.3 35.3 75.3 74 1.3 7.1 1 7.1 3 MZE0710MA 22.6 46.3 46.3 88.3 87 1.3 7.1 1 7.2 2 MZE0720SA 15.7 35.3 35.3 75.3 74 1.3 7.2 1 7.2 3 MZE0720MA 22.9 46.3 46.3 88.3 87 1.3 7.2 1 7.3 2 MZE0730SA 15.9 35.3 35.3 75.3 74 1.3 7.3 1 7.3 3 MZE0730MA 23.2 46.3 46.3 88.3 87 1.3 7.3 1 7.4 2 MZE0740SA 16.1 35.3 35.3 75.3 74 1.3 7.4 1 7.4 3 MZE0740MA 23.5 46.3 46.3 88.3 87 1.3 7.4 1 7.5 2 MZE0750SA 16.4 35.4 35.4 75.4 74 1.4 7.5 1 7.5 3 MZE0750MA 23.9 46.4 46.4 88.4 87 1.4 7.5 1 7.6 2 MZE0760SA 16.6 38.4 38.4 80.4 79 1.4 7.6 1 7.6 3 MZE0760MA 24.2 49.4 49.4 91.4 90 1.4 7.6 1 7.7 2 MZE0770SA 16.8 38.4 38.4 80.4 79 1.4 7.7 1 7.7 3 MZE0770MA 24.5 49.4 49.4 91.4 90 1.4 7.7 1 7.8 2 MZE0780SA 17.0 38.4 38.4 80.4 79 1.4 7.8 1 7.8 3 MZE0780MA 24.8 49.4 49.4 91.4 90 1.4 7.8 1 7.9 2 MZE0790SA 17.2 38.4 38.4 80.4 79 1.4 7.9 1 7.9 3 MZE0790MA 25.1 49.4 49.4 91.4 90 1.4 7.9 1 8.0 2 MZE0800SA 17.5 38.5 38.5 80.5 79 1.5 8.0 1 8.0 3 MZE0800MA 25.5 49.5 49.5 91.5 90 1.5 8.0 1 8.1 2 MZE0810SA 17.7 38.5 38.5 80.5 79 1.5 8.1 1 8.1 3 MZE0810MA 25.8 54.5 54.5 97.5 96 1.5 8.1 1 8.2 2 MZE0820SA 17.9 38.5 38.5 80.5 79 1.5 8.2 1 8.2 3 MZE0820MA 26.1 54.5 54.5 97.5 96 1.5 8.2 1 8.3 2 MZE0830SA 18.1 38.5 38.5 80.5 79 1.5 8.3 1 8.3 3 MZE0830MA 26.4 54.5 54.5 97.5 96 1.5 8.3 1 8.4 2 MZE0840SA 18.3 38.5 38.5 80.5 79 1.5 8.4 1 8.4 3 MZE0840MA 26.7 54.5 54.5 97.5 96 1.5 8.4 1 8.5 2 MZE0850SA 18.5 38.5 38.5 80.5 79 1.5 8.5 1 8.5 3 MZE0850MA 27.0 54.5 54.5 97.5 96 1.5 8.5 1 8.6 2 MZE0860SA 18.8 41.6 41.6 85.6 84 1.6 8.6 1 8.6 3 MZE0860MA 27.4 56.6 56.6 99.6 98 1.6 8.6 1 8.7 2 MZE0870SA 19.0 41.6 41.6 85.6 84 1.6 8.7 1 8.7 3 MZE0870MA 27.7 56.6 56.6 99.6 98 1.6 8.7 1 8.8 2 MZE0880SA 19.2 41.6 41.6 85.6 84 1.6 8.8 1 8.8 3 MZE0880MA 28.0 56.6 56.6 99.6 98 1.6 8.8 1 / CUTTING CONDITIONS >P127 OPERATION GUIDANCE >>P129 TECHNICAL DATA > R001
