ISCARDEEPDRiLL Requested Information Form for Deep Hole Drill Design (continued) TUBE Outside diameter: (mm/inch) Total Lenqth: (mm/inch) nternal Thread: =xternal Thread: 4 Starts 2 Starts 1 Starts Tube Thread: 1 End Both ends nner Tube Length: (mm/inch) nner Tube Slit: 1 E nd Both ends Drilling System & Boring Conditions Single Tube System: Blind Hole Drilling: Double Tube System: Cross Hole Drilling: Through Hole Drilling: Please sketch your drilling application GENERAL PRODUCTION INFORMATION Quantity of parts per year: Grade, tool life, etc.: Perfomance expectation: Vc= mm/min N= RPM F= mm/min f= mm/rev Cutting data: Description of present system in use: Please fill in and return to your ISCAR representative. Member IMC Group kSSlIf USER GUIDE DEEP HOLE DRILLING
