ISCAR Milling Grades Chart Recommended Applications A cermet grade. Provides excellent resistance to wear and plastic deformation even at high cutting speeds and medium feeds. Useful for turning and milling of semi-finishing and finishing applications. An uncoated, fine grain carbide grade. Used for high temperature alloys and stainless steel at low to medium cutting speeds. An uncoated carbide grade. Used for semi-finishing, finishing and semi-roughing of aluminum, cast iron and stainless steel. Used at low to medium speeds and feeds. An uncoated, fine grain carbide grade. Used for stainless steel and high temperature alloys at low to medium cutting speeds. An uncoated carbide grade. Used mainly for machining aluminum at medium cutting speeds with medium to large chip sections. The inserts usually feature very sharp cutting angles. An uncoated carbide grade. Recommended for semi-finishing to rough steel milling with medium to large chip sections. A 55% CBN brazed tip, used for finishing hardened steel (45-65 HRc) in continuous cutting. An 85% CBN brazed tip, used for high speed turning of cast iron, cemented tungsten carbide, sintered metals and heavy alloys. Excellent for interrupted cutting of hardened steel. A PCD brazed tip, suitable for machining aluminum (Si < 12%) and copper alloys and general cutting of nonferrous materials. A PCD grade for milling applications. Ideal for machining nonferrous metals, such as high silicon (>12%) aluminum alloys and metal matrix composites. Typical components: engine, gearbox and transmission components, disk brakes, glass epoxy parts, etc. A silicon nitride grade, used for medium turning and milling applications. Can be used for interrupted cuts. Cutting speed range: 100-1500 m/min, feed range: 0.1-1.0 mm/rev. 1005 MATERIALS AND GRADES
