Hoffmann Group 47 Pictograms Use of Cirdip pliers Shank version, masonry drills and chisels Tool material, masonry drills Use of masonry drills and chisels /°°\ /°°v HM Carbide For internal rings/holes Cylindrical For use in machines with impart medianism 3 F“r external rings/sfiafts J 1/4" hexagon shank to DIN 3126 E6.3 E6,3 Rotary use only. Not suitable for hammer drills. Insulation ESD /PEN 1000V (£> Cutting chamfer on electronics side cutters Fully insulated up to 1000V to EN 60900/VDE 0682 Marking of EHA tools (Electrostatic Hazard Area), which avoid the occurrence of electrostatic charges/discharges (ESD Electrostatic Discharge). DIN EN 100015 specifies a discharge resistance of between 104-1011 Ohm for the handles of these tools. No bevel Very fine bevel Fine bevel KW SFW FW W The individual cutting operations are differentiated by the upper and lower pressure distribution. The finer the bevel on the jaw the less burr on the cut surfaces. Side cutters with no bevel give a virtually burr-free surface (ideal for soldered joints). Colour coding system for the application range of side cutters: Material Strength N/mm2 Example Copper, plastics soft upto250 Copper wire, plastics Steel, bronze medium hard 500-1000 Nails, wire nails Steel hard 1400- 2200 Wire cables, spring wire Steel piano wire from 2200 hardened spring wire Conversion table AWG into conductor cross section (mm2) or conductor 0 (0 mm without insulation) AWS 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 mm2 0,0324 0,04 0,0516 0,0646 0,08 0,102 0,128 0,163 0,205 0,259 0,325 0,412 0,519 0,653 0,823 1,04 1,31 0 mm 0,2 0,23 0,26 0,29 0,32 0,36 0,4 0,46 0,5 0,57 0,64 0,72 0,81 0,91 1,02 1,15 1,3 AWS 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 1/0 2/0 mm2 1,65 2,08 2,63 3,31 4,15 5,27 6,62 8,35 10,6 13,3 16,8 21,2 26,7 33,6 42,4 53,4 67,5 0 mm 1,4 1,6 1,8 2,1 2,3 2,6 2,9 3,3 3,7 4,1 4,6 5,2 5,8 6,5 7,3 8,2 9,3 hole . Snipe-nose pliers set 3-piece, long version Robust pliers of chrome vanadium steel, nickel-plated. Double plastic coating on the handles for good grip, inner faces of jaws serrated. Application: Gripping and assembling recessed or inaccessible parts. Number of pliers 3 s 70 0115 Snipe-nose pliers set long version 3-piece 27.03 Supplied with: 1 snipe nose pliers, straight 280 mm 1 snipe-nose pliers 45° angled 280 mm 1 mechanic's pliers (extractor pliers for spark plugs) 280 mm r 634
