SPECIALIST TOOLING 1000V INSULATED TOOLS FACOM VSE INSULATED ELECTRICAL PRODUCTION TOOLS FOR CORRECT USE OF INSULATED TOOLS FOR CORRECT USE OF INSULATED TOOLS ALWAYS Wear insulating gloves and eye protection Check insulation is sound before using a tool. Never use a tool with insulation that is cracked cut or damaged in any way. products come with safety RECOMMENDATIONS Beware of electrical danger Make sure insulation is not damaged by Heat (-20C to 70C working temperature) Cuts or perforations Chemicals. Visually check insulation before use. Wear insulating gloves and eye protection 2-colour insulation Orange safe Yellow STOP SAFETY CERTIFICATION Insulation Certified end accredited Facom production site Tested and approved products.. 2-colour warning" insulation Orange 1000V protection. Yellow visible Stop and replace tool Basic tool Facom performance and safety. Reference and technical data Hand stays clear of the metal. Traceability Ribbing on flexible insulation for more secure handling. Every tool carries approval markings. Facom products comply with European Electro-technical Standards Commission EN 60900 specifications. SAFETY COLOUR CODING Year and week of insulation. Major European test-laboratory symbols certify EN 60900 conformity of both tool and manufacturing process. ORANGE 1000V PROTECTION YELLOW VISIBLE STOP. REPLACE TOOL "2-colour warning" insulation is applied by dipping in the area where the hand grips the tool. Y TOOLS TO EN60900 SPECIFICATIONS Individual production test Every tool is tested to 10 000V for 10 seconds at the end of the manufacturing cycle. After 24 hours immersion the tool is wiped and tested to 1000CJV for 3 minutes between metal and sheath surface. Leakage current should not exceed specified limits. B Penetration test After a penetration test on the most vulnerable part of the tool followed by heating and cooling down no breakdown or flashover should occur when 5000 volts is applied for 3 minutes. A 50 kg tear test is carried out for 3 minutes at ambient temperature on a tool heated to 70 Cfor 168 hours. Sheath and guard should remain bonded to the metal. After exposure to a flame for 10 seconds flame spread over the tool should not exceed 120 mm high within the next 20 seconds. El Impact test A standard force is repeatedly applied to the handle end of a tool chilled to -25 C for 2 hours. The sheathing should not crack. catalogue FACOM F05 631
