DC (mm) 5 Hole Depth DP3020 Order Number Dimensions (mm) 0 CL P 3 l Li. o l X i i O Ll. l i CL DCON 6.0 8 MQS0600X8DB 49.2 67.2 67.2 119.2 118 1.2 6 1 6.1 3 MQS0610X3DB 19.6 34.3 36.3 87.3 86 1.3 7 1 6.1 5 MQS0610X5DB 31.8 47.3 49.3 96.3 95 1.3 7 1 6.2 3 MQS0620X3DB 19.9 34.3 36.3 87.3 86 1.3 7 1 6.2 5 MQS0620X5DB 32.3 47.3 49.3 96.3 95 1.3 7 1 6.3 3 MQS0630X3DB 20.2 34.3 36.3 87.3 86 1.3 7 1 6.3 5 MQS0630X5DB 32.8 47.3 49.3 96.3 95 1.3 7 1 6.4 3 MQS0640X3DB 20.5 34.3 36.3 87.3 86 1.3 7 1 6.4 5 MQS0640X5DB 33.3 47.3 49.3 96.3 95 1.3 7 1 6.5 3 MQS0650X3DB 20.8 34.3 36.3 87.3 86 1.3 7 1 6.5 5 MQS0650X5DB 33.8 47.3 49.3 96.3 95 1.3 7 1 6.5 8 MQS0650X8DB 53.3 73.3 78.3 131.3 130 1.3 7 1 6.6 3 MQS0660X3DB 21.2 36.4 38.4 91.4 90 1.4 7 1 6.6 5 MQS0660X5DB 34.4 50.4 52.4 99.4 98 1.4 7 1 6.7 3 MQS0670X3DB 21.5 36.4 38.4 91.4 90 1.4 7 1 6.7 5 MQS0670X5DB 34.9 50.4 52.4 99.4 98 1.4 7 1 6.8 3 MQS0680X3DB 21.8 36.4 38.4 91.4 90 1.4 7 1 6.8 5 MQS0680X5DB 35.4 50.4 52.4 99.4 98 1.4 7 1 6.9 3 MQS0690X3DB 22.1 36.4 38.4 91.4 90 1.4 7 1 6.9 5 MQS0690X5DB 35.9 50.4 52.4 99.4 98 1.4 7 1 7.0 3 MQS0700X3DB 22.4 36.4 38.4 91.4 90 1.4 7 1 7.0 5 MQS0700X5DB 36.4 50.4 52.4 99.4 98 1.4 7 1 7.0 8 MQS0700X8DB 57.4 78.4 78.4 131.4 130 1.4 7 1 7.1 3 MQS0710X3DB 22.8 39.5 40.5 91.5 90 1.5 8 1 7.1 5 MQS0710X5DB 37.0 54.5 57.5 104.5 103 1.5 8 1 7.2 3 MQS0720X3DB 23.1 39.5 40.5 91.5 90 1.5 8 1 7.2 5 MQS0720X5DB 37.5 54.5 57.5 104.5 103 1.5 8 1 7.3 3 MQS0730X3DB 23.4 39.5 40.5 91.5 90 1.5 8 1 7.3 5 MQS0730X5DB 38.0 54.5 57.5 104.5 103 1.5 8 1 7.4 3 MQS0740X3DB 23.7 39.5 40.5 91.5 90 1.5 8 1 7.4 5 MQS0740X5DB 38.5 54.5 57.5 104.5 103 1.5 8 1 7.5 3 MQS0750X3DB 24.1 39.6 40.6 91.6 90 1.6 8 1 7.5 5 MQS0750X5DB 39.1 54.6 57.6 104.6 103 1.6 8 1 7.5 8 MQS0750X8DB 61.6 84.6 89.6 143.6 142 1.6 8 7.6 3 MQS0760X3DB 24.4 41.6 41.6 91.6 90 1.6 8 1 7.6 5 MQS0760X5DB 39.6 57.6 57.6 104.6 103 1.6 8 1 7.7 3 MQS0770X3DB 24.7 41.6 41.6 91.6 90 1.6 8 1 7.7 5 MQS0770X5DB 40.1 57.6 57.6 104.6 103 1.6 8 1 7.8 3 MQS0780X3DB 25.0 41.6 41.6 91.6 90 1.6 8 1 7.8 5 MQS0780X5DB 40.6 57.6 57.6 104.6 103 1.6 8 1 7.9 3 MQS0790X3DB 25.3 41.6 41.6 91.6 90 1.6 8 1 7.9 5 MQS0790X5DB 41.1 57.6 57.6 104.6 103 1.6 8 1 8.0 3 MQS0800X3DB 25.7 41.7 41.7 91.7 90 1.7 8 1 8.0 5 MQS0800X5DB 41.7 57.7 57.7 104.7 103 1.7 8 1 8.0 8 MQS0800X8DB 65.7 89.7 89.7 143.7 142 1.7 8 8.1 3 MQS0810X3DB 26.0 44.7 46.7 97.7 96 1.7 9 1 8.1 5 MQS0810X5DB 42.2 61.7 63.7 114.7 113 1.7 9 1 8.2 3 MQS0820X3DB 26.3 44.7 46.7 97.7 96 1.7 9 1 8.2 5 MQS0820X5DB 42.7 61.7 63.7 114.7 113 1.7 9 1 8.3 3 MQS0830X3DB 26.6 44.7 46.7 97.7 96 1.7 9 1 DC (mm) 5 Hole Depth DP3020 Order Number Dimensions (mm) D CL P 3 l Ll. O l X i i O Ll. l i a. DCON 8.3 5 MQS0830X5DB 43.2 61.7 63.7 114.7 113 1.7 9 1 8.4 3 MQS0840X3DB 26.9 44.7 46.7 97.7 96 1.7 9 1 8.4 5 MQS0840X5DB 43.7 61.7 63.7 114.7 113 1.7 9 1 8.5 3 MQS0850X3DB 27.3 44.8 46.8 97.8 96 1.8 9 1 8.5 5 MQS0850X5DB 44.3 61.8 63.8 114.8 113 1.8 9 1 8.5 8 MQS0850X8DB 69.8 95.8 100.8 155.8 154 1.8 9 2 8.6 3 MQS0860X3DB 27.6 46.8 48.8 102.8 101 1.8 9 1 8.6 5 MQS0860X5DB 44.8 64.8 66.8 117.8 116 1.8 9 1 8.7 3 MQS0870X3DB 27.9 46.8 48.8 102.8 101 1.8 9 1 8.7 5 MQS0870X5DB 45.3 64.8 66.8 117.8 116 1.8 9 1 8.8 3 MQS0880X3DB 28.2 46.8 48.8 102.8 101 1.8 9 1 8.8 5 MQS0880X5DB 45.8 64.8 66.8 117.8 116 1.8 9 1 8.9 3 MQS0890X3DB 28.5 46.8 48.8 102.8 101 1.8 9 1 8.9 5 MQS0890X5DB 46.3 64.8 66.8 117.8 116 1.8 9 1 9.0 3 MQS0900X3DB 28.9 46.9 48.9 102.9 101 1.9 9 1 9.0 5 MQS0900X5DB 46.9 64.9 66.9 117.9 116 1.9 9 1 9.0 8 MQS0900X8DB 73.9 100.9 100.9 155.9 154 1.9 9 2 9.1 3 MQS0910X3DB 29.2 49.9 51.9 102.9 101 1.9 10 1 9.1 5 MQS0910X5DB 47.4 68.9 71.9 122.9 121 1.9 10 1 9.2 3 MQS0920X3DB 29.5 49.9 51.9 102.9 101 1.9 10 1 9.2 5 MQS0920X5DB 47.9 68.9 71.9 122.9 121 1.9 10 1 9.3 3 MQS0930X3DB 29.8 49.9 51.9 102.9 101 1.9 10 1 9.3 5 MQS0930X5DB 48.4 68.9 71.9 122.9 121 1.9 10 1 9.4 3 MQS0940X3DB 30.1 49.9 51.9 102.9 101 1.9 10 1 9.4 5 MQS0940X5DB 48.9 68.9 71.9 122.9 121 1.9 10 1 9.5 3 MQS0950X3DB 30.5 50.0 52.0 103.0 101 2.0 10 1 9.5 5 MQS0950X5DB 49.5 69.0 72.0 123.0 121 2.0 10 1 9.5 8 MQS0950X8DB 78.0 107.0 112.0 168.0 166 2.0 10 2 9.6 3 MQS0960X3DB 30.8 52.0 52.0 103.0 101 2.0 10 1 9.6 5 MQS0960X5DB 50.0 72.0 72.0 123.0 121 2.0 10 1 9.7 3 MQS0970X3DB 31.1 52.0 52.0 103.0 101 2.0 10 1 9.7 5 MQS0970X5DB 50.5 72.0 72.0 123.0 121 2.0 10 1 9.8 3 MQS0980X3DB 31.4 52.0 52.0 103.0 101 2.0 10 1 9.8 5 MQS0980X5DB 51.0 72.0 72.0 123.0 121 2.0 10 1 9.9 3 MQS0990X3DB 31.8 52.1 52.1 103.1 101 2.1 10 1 9.9 5 MQS0990X5DB 51.6 72.1 72.1 123.1 121 2.1 10 1 10.0 3 MQS1000X3DB 32.1 52.1 52.1 103.1 101 2.1 10 1 10.0 5 MQS1000X5DB 52.1 72.1 72.1 123.1 121 2.1 10 1 10.0 8 MQS1000X8DB 82.1 112.1 112.1 168.1 166 2.1 10 2 10.1 3 MQS1010X3DB 32.4 55.1 57.1 113.1 111 2.1 11 1 10.1 5 MQS1010X5DB 52.6 76.1 80.1 136.1 134 2.1 11 1 10.2 3 MQS1020X3DB 32.7 55.1 57.1 113.1 111 2.1 11 1 10.2 5 MQS1020X5DB 53.1 76.1 80.1 136.1 134 2.1 11 1 10.3 3 MQS1030X3DB 33.0 55.1 57.1 113.1 111 2.1 11 1 10.3 5 MQS1030X5DB 53.6 76.1 80.1 136.1 134 2.1 11 1 10.4 3 MQS1040X3DB 33.4 55.2 57.2 113.2 111 2.2 11 1 10.4 5 MQS1040X5DB 54.2 76.2 80.2 136.2 134 2.2 11 1 10.5 3 MQS1050X3DB 33.7 55.2 57.2 113.2 111 2.2 11 1 10.5 5 MQS1050X5DB 54.7 76.2 80.2 136.2 134 2.2 11 1 10.5 8 MQS1050X8DB 86.2 118.2 123.2 184.2 182 2.2 11 2 / CUTTING CONDITIONS >P054 OPERATION GUIDANCE > P056 TECHNICAL DATA > R001
