rsnMiiHrucO HOLEX Combination spanner Version Drop forged. With close tolerance jaw width. GARANT With easy-grip profile shaft. Exceptional tool life and wear resistance. Ring end with AS-drive profile. STAHLWILLE With easy-grip fluted shaft. Optimum flex resistance, good torque transmission. Ring end with AS-drive profile. (Sizes 3.2 - 5 with hexagon). HOLEX With oval shaft. Combination spanner, normal version Standard DIN 3113 A / ISO 3318 / ISO 7738 Material GARANT - Chrome alloy steel, non-flaking chrome-plated; smoothed finish surface. STAHLWILLE - Chrome alloy steel, non-flaking chrome-plated over nickel; smoothed finish surface. 61 3900/3910- HOLEX - Chrome vanadium steel, phosphated. 61 3950/3960/3970- HOLEX - Chrome vanadium steel, chrome-plated. Width across flats mm 61 3700 61 3500 MUMUEO Combination spanner 61 3900 HOLEX Combination spanner phosphated 361 3950 HOLEX Combination spanner chrome-plated L 61 3700 61 3500 mm L 61 3900 61 3950 mm hi max. mm h2 max. mm I jfecmnt I Combination spanner 3,2 75 3 3.2 3,5 75 - 3 3.2 4 85 100 4 6 4,5 85 100 4 6 5 95 100 4 6 5,5 100 100 4 6 6 105 100 4 6 7 110 110 4 7 8 115 120 4.5 7 9 120 130 4.5 8 10 125 140 5 9 11 135 150 5.5 10 12 140 160 5.5 10 13 160 170 6.5 11 14 165 180 6.5 12 15 170 190 7 12 16 180 200 8 13 17 190 210 8 13 18 200 220 9 14 19 230 230 9 14 20 230 240 9 14 21 260 250 10 15 22 260 260 10 15 23 280 270 10 15 24 280 280 12 16 25 300 290 12 16 27 300 310 13 18 30 330 340 14 20 32 360 360 14 21 34 450 380 14 21 36 460 400 15 24 38 480 - 11 19 41 480 442 17 26 46 500 492 18 28 50 530 - 14 21 55 560 - 15 22 60 590 - 16 24 Width across flats inch s 613520 saniM/ai (y Combination spanner, inch s 613970 HOLDf. Combination spanner, inch chrome-plated L 61 3520 mm L 61 3970 mm hi max. mm h2 max. mm 13/64 95 - 3 3.2 7/32 95 - 3 3.2 15/64 95 3 3.2 1/4 105 101 4 6 9/32 110 - 3.9 6 5/16 115 121 4.5 7 11/32 120 4.5 7 3/8 125 141 5 9 7/16 135 151 5.5 10 1/2 160 171 6.5 11 9/16 165 181 6.5 12 19/32 170 - 5.3 8.5 5/8 180 201 8 13 11/16 200 211 8 13 3/4 230 231 9 14 25/32 235 - 7 13 13/16 260 251 10 15 7/8 260 261 10 15 15/16 280 281 12 16 1 300 291 12 16 1.1/16 300 - 8.4 14.5 1.1/8 330 - 8.9 16 1.1/4 360 9.4 16.5 1.5/16 450 9.6 17 1.1/2 480 - 11 19 Note AS drive the special profile. An extremely accurately fittirW Jt) profile - developed for aviation- and aerospace. Tools with this profile can be recognised by the AS-drive symbol. Advantages Bolts are gripped on the flanks. - The corners are protected. - Longer bolt life. Greater bearing surfaces between bolt and tool. - Secure grip and higher torque transmission. 613700 Ring end AS drive 61 3500 Ring end AS drive 61 3900 61 3520 Ring end AS drive 61 3970 Main catalogue Hoffmann Group 46 1129
