1479 Каталог MITSUBISHI 2015 Токарный и вращающийся инструмент Инструментальные решения Стр.N163

Каталог MITSUBISHI 2015 Металлорежущий инструмент Стр. N163 1479 ENG Lab2u

Order Number DC LCF OAL LF PL DCON Order Number DC LCF OAL LF PL DCON 1 W VSDD0850 8.5 75.6 123.6 121 2.6 8.5 VSDD1080 10.8 95.2 143.2 140 3.2 10.8 5 D0860 8.6 81.6 123.6 121 2.6 8.6 VSE D1090 10.9 95.3 143.3 140 3.3 10.9 D0870 8.7 81.6 123.6 121 2.6 8.7 D1100 11.0 95.3 143.3 140 3.3 11.0 5E D0880 8.8 81.6 126.6 124 2.6 8.8 VS D1110 11.1 95.3 143.3 140 3.3 11.1 5E D0890 8.9 81.7 126.7 124 2.7 8.9 D1120 11.2 95.4 146.4 143 3.4 11.2 D0900 9.0 81.7 126.7 124 2.7 9.0 VS D1130 11.3 95.4 146.4 143 3.4 11.3 D0910 9.1 81.7 126.7 124 2.7 9.1 D1140 11.4 95.4 146.4 143 3.4 11.4 D0920 9.2 81.8 129.8 127 2.8 9.2 VSE D1150 11.5 95.5 146.5 143 3.5 11.5 5E D0930 9.3 81.8 129.8 127 2.8 9.3 D1160 11.6 95.5 149.5 146 3.5 11.6 D0940 9.4 81.8 129.8 127 2.8 9.4 VSE D1170 11.7 95.5 149.5 146 3.5 11.7 5E D0950 9.5 81.9 129.9 127 2.9 9.5 D1180 11.8 95.5 149.5 146 3.5 11.8 5E D0960 9.6 87.9 132.9 130 2.9 9.6 VSE D1190 11.9 102.6 149.6 146 3.6 11.9 D0970 9.7 87.9 132.9 130 2.9 9.7 D1200 12.0 102.6 152.6 149 3.6 12.0 D0980 9.8 87.9 132.9 130 2.9 9.8 VSE D1210 12.1 102.6 152.6 149 3.6 12.1 D0990 9.9 88.0 133.0 130 3.0 9.9 D1220 12.2 102.7 152.7 149 3.7 12.2 5E D1000 10.0 88.0 133.0 130 3.0 10.0 VSE D1230 12.3 102.7 152.7 149 3.7 12.3 5 D1010 10.1 88.0 136.0 133 3.0 10.1 D1240 12.4 102.7 155.7 152 3.7 12.4 5E D1020 10.2 88.1 136.1 133 3.1 10.2 VSE D1250 12.5 102.8 155.8 152 3.8 12.5 5E D1030 10.3 88.1 136.1 133 3.1 10.3 D1260 12.6 102.8 155.8 152 3.8 12.6 D1040 10.4 88.1 136.1 133 3.1 10.4 VSE D1270 12.7 102.8 155.8 152 3.8 12.7 D1050 10.5 88.2 140.2 137 3.2 10.5 D1280 12.8 102.8 155.8 152 3.8 12.8 D1060 10.6 88.2 140.2 137 3.2 10.6 VSE D1290 12.9 102.9 155.9 152 3.9 12.9 D1070 10.7 95.2 140.2 137 3.2 10.7 D1300 13.0 102.9 155.9 152 3.9 13.0 RECOMMENDED CUTTING CONDITIONS Work Material Structural steel Carbon steel AISI 1049 Stainless steel AISI 420 Stainless steel AISI 304 Tool steel AISI D2 (Low-hardness materials) Heat-treated steel AISI H13 (-40HRC) Cutting speed 40m/min 30m/min 20m/min 10 14m/min Drill Dia. DC (mm) Revolution (min'1) Feed rate (mm/rev) Revolution (min'1) Feed rate (mm/rev) Revolution (min'1) Feed rate (mm/rev) Revolution (min'1) Feed rate (mm/rev) 0.5 15000 0.01 11250 0.01 7500 0.01 5620 0.01 1.0 10000 0.02 7500 0.02 5000 0.02 3750 0.02 1.5 8200 0.03 6150 0.03 4100 0.03 2800 0.03 2.0 6370 0.05 4780 0.05 3180 0.05 2200 0.04 3.0 4250 0.10 3180 0.10 2120 0.07 1400 0.06 4.0 3180 0.13 2390 0.13 1590 0.09 1100 0.08 5.0 2550 0.15 1910 0.15 1270 0.11 860 0.10 6.0 2120 0.18 1590 0.18 1060 0.13 720 0.11 7.0 1820 0.20 1360 0.20 910 0.14 610 0.12 8.0 1590 0.22 1190 0.21 800 0.15 540 0.13 9.0 1420 0.24 1060 0.22 710 0.17 480 0.14 10.0 1270 0.26 960 0.23 640 0.18 430 0.15 11.0 1160 0.28 870 0.24 580 0.19 390 0.16 12.0 1060 0.30 800 0.25 530 0.20 360 0.17 13.0 980 0.30 730 0.26 490 0.20 330 0.17 1) Please reduce the revolution depending on drilling situation when the application lacks rigidity. 2) Please use step drilling and reduce the cutting conditions in the case when the drilling depth exceeds 3DC (DC drill diameter). 3) The above-mentioned cutting condition is standard when using water-soluble cutting fluid. Please reduce the revolution when using non-water-soluble cutting fluid.
