WIDIA R8 Shank Tools Catalog Numbering System How Do Catalog Numbers Work Each character in our catalog number signifies a specific trait of that product. Use the following key columns and corresponding images to easily identify which attributes apply. WIDIA R8DA188181 jcztl.lklLM: R8 DA Shank Style Toolholder Style DA = Double-angle collet chuck EM = End mill adapter SM = Shell mill adapter 188 181 Toolholder Size Tool Length (Tool gage line to front of tool) inch xxx = x.xx DA = Collet series xxx (188) EM = I.D. size: metric xx = xx, (20); inch xxx = x.xx, (075) SM = O.D. size: metric xx = xx, (20); inch xxx = x.xx, (075)
