Reaming WALTER TITEX =slxd I 1 through hole depth < 1 x d r through hole depth > 1 x d blind hole DIN 2179 DIN 2180 DIN 311 Walter standard DIN 206 DIN 859 c F3234 F6134 F4535 F3517 F1111 F1131 F1211 F1231 Hand reamer Hand reamer Adjustable hand reamer Adjustable hand reamer For tapered holes 1:50 For tapered holes 1:50 Bridge reamers For tapered holes 1:10 Straight flute Left-hand helix Straight flute Left-hand helix 1.00 12.00 5.00 20.00 6.40 32.00 5.00 23.00 1.00 30.00 1.00 50.00 4.00 30.00 8.00 30.00 HSS-E HSS uncoated A >% rrf-i i rfi i A B 340 B 350 B 349 B 342 B 322 B 323 B 326 B 327 j 1 B 321
