GUNDRILLS USER GUIDE ISCAR SUMOGUN Inquiry Form 1. Tool Quantity Nominal diameter and tolerance Please fill in dimensions on the sketch below. Sketch of drilling application Driver Driver: for standard drivers please use codes from page 656 .. Code No. Special, please attach sketch and specifications. 2. Workpiece (If possible, please attach a drawing) 2.1 Material Material description (DIN material number or any other standard): Hardness and Properties: Short Chips Long Chips 2.2 Hole Type Blind Hole Drilling into Pre-hole Angled Entry Drilling into Solid Boring Angled Exit Drilling Depth mm Hole Tolerance 2.3 Application: Workpiece: Stationary : Rotating Tool: Stationary : Rotating 3. Machine 3.1 Technical Data Specially Tailored SUMOGUN Code Key Note: It may be necessary to change several of the parameters that you indicated, based on our experience with your application. Machine Type Power: kW .. 3.2 Cutting Data: Cutting Speed Vc m/min .. Revolutions Nmin .. RPM, Nmax .RPM Feed Fmin mm/rev, Fmax mm/rev Feed Rate VF .. mm/min Coolant: Oil Soluble Oil Coolant Pressure Other Bar .. Machine Type Обозначение Designation D Required L Drilling Length L1 Total Length Driver (1) Code For GUNDRILL machines MNGDT 1500-1000-MF X1-T2 D L1 Driver Code (D , L1, , Driver Code, 15.00 920 1000 23 For other machine tools (1) see page 656 15.00 920 1000 23 Drilling Head Mounting Procedure 660 ISCAR
