DEEP HOLE DRILLING QUESTIONNAIRE Campany Name Address Contact person r 1 WORKPIECE (If possibleplease attach a drawing) Product Name Hole diameter (0) (in) Hole depth (drilling length) (in) No. of holes Tolerance (of hole) Surface finish (RzRa...) Deviation (mm 100) Straightness (mm 100) Material Material (DINAISIJIS...) Hardness (HBHSHRC...) Condition Annealed Quenched Tempered Cast Other Inquiry Number Inquiry Date Customer No Machine supplier name Machine type model Rigidity Good Normal Bad Date of manufacture Retrofitted NC lathe M C Other Double rotation(TR WR) Tool and Workpiece Rotating workpiece(WR) Rotating tool(IR) Safety devices V Motors power TYPE OF COOLANT Coolant supplier name Water based Soluble Emulsion % Oil based Coolant Pressure Coolant Volume a f TOOL Drill Head Drill diameter(0) (in) Thread Inner Outer Brazed Indexable Adjustable Direct mount Coating Coated Uncoated Coating type TiN TiAlN Other Solid drilling Counterboring Cutting brazed 20 45 angle indexable nomal angle close angle Pre-bored size(per side) (in) Bottom finishing Fullball R Flatbottom R Corner R Compound R Trepanning Core size(0) (in) Tube inner dia(0) (in) Tube outer dia(0) (in) Tube Outside Dia(0) (in) Total Length(L) (in) Internal Thread External Thread 4 Starts 2 Starts 1 Start Tube thread 1 end Both ends Inner Tube Length (in) Inner Tube Slit 1 End Both ends DRILLING SYSTEM 'i Single tube system TS ST Double tube system TS DT BORING CONDITIONS Through hole drilling Blind hole drilling Cross hole drilling GENERAL INFORMATION Production Quantity per year: Present Performance Status: gradetool lifeetc: Cutting Data: Vc SFM N rpm f in re F in min 60RE ne
