Machine reamer HOLEX with Morse taper shank Version Application H7 HSS E DIN 208 B m MT1-4 Even number of teeth with irregular spacing The hole i

Machine reamer HOLEX with Morse taper shank Version Application H7 HSS E DIN 208 B m MT1-4 Even number of teeth with irregular spacing. The hole is accurately round and free of chatter marks. The cylindrical ground land on the plain cutting section smoothes the hole and guides the reamer. With Morse taper shank For reaming through holes, as the swarf is evacuated in cutting direction. Also suitable for blind holes due to the short chamfer lead. Even number of teeth with irregular spacing; two teeth are exactly opposite each other, e.g. tooth 1 and 5. Suitable for/ vc m/min Alu plastics G Alu cast >10% Si <500 N <750 N <900 N <1100N <1400 N n n 900 N Ti >850 N GG(G) Cu Gra G C I Uni ‘ES' JTT1 max min Air ISO code N P H K N 164000-4180- 13 11 11 7 7 5 4 5 5 5 5 13 1 1 Reamer for fit H7 Version Reamer finish ground for fit H 7. Nominal 0 mm S164000 holhC. Machine reamer H7 i mm J Uot mm s MT <750 N Nominal 0 mm 164000 hqleX. Machine reamer H7 mm 3 1 s MT <750N Nominal 0 mm 164000 HOIf/. Machine reamer H7 i mn 1 Uot mm s MT <750 N f mm/rev f mm/rev f mm/rev 5 67 133 1 0.10 16 130 210 2 0.20 30 182 281 3 0.30 6 72 138 1 0.10 17 134 214 2 0.20 32 193 317 4 0.30 7 84 150 1 0.10 18 139 719 2 0.20 34 197 321 4 0.30 8 90 156 1 0.13 19 143 223 2 0.20 35 197 321 4 0.30 9 9fi 16 1 0.13 20 148 228 2 0.25 36 201 325 4 0.30 10 102 168 1 0.15 22 157 237 2 0.25 38 205 329 4 0.30 11 109 175 1 0.15 23 161 241 2 0.25 40 205 329 4 0.35 12 116 182 1 0.15 24 169 268 3 0.25 42 209 333 4 0.35 13 116 182 1 0.15 25 169 268 3 0.25 44 212 336 4 0.35 14 123 189 1 0.15 26 174 273 3 0.25 45 212 336 4 0.35 15 124 204 2 0.20 28 178 277 3 0.25 50 220 344 4 0.40 Reamer similar to No. 164000, non-standard sizes and fits Version Reamer finish ground to fit your specifications. Note For fit H7 see No. 164000. Nominal 0 mm 1 164180 HOtfX. Machine reamer 0 range mm s mm ;:i Uot mm i MT <750 N Nominal 0 mm 1 164180 HOLEX Machine reamer 0 range mm s mm 1 Uot mm i MT <750 N f mm/rev f mm/rev 4 3.60- 4.10 58 124 1 0.10 22,5 22.21-22.50 161 241 2 0.25 4,5 4.11- 4.50 58 133 1 0.10 23 22.51-23.20 161 241 2 0.25 5 4.51- 5.10 67 133 1 0.10 23,5 23.21-23.50 161 268 3 0.25 5,5 5.11- 5.50 72 138 1 0.10 24 23.51-24.20 169 268 3 0.25 6 5.51- 6.10 72 138 1 0.10 24,5 24.21-24.50 169 268 3 0.25 6,5 6.11- 6.50 78 150 1 0.10 25 24.51-25.20 169 268 3 0.25 7 6.51- 7.10 84 150 1 0.10 25,5 25.21-25.50 174 273 3 0.25 7,5 7.11- 7.50 84 156 1 0.10 26 25.51-26.20 174 273 3 0.25 8 7.51- 8.10 90 156 1 0.13 26,5 26.21-26.50 174 277 3 0.25 8,5 8.11- 8.50 90 162 1 0.13 27 26.51-27.20 178 277 3 0.25 9 8.51- 9.10 96 162 1 0.13 27,5 27.21-27.50 178 277 3 0.25 9,5 9.11- 9.50 96 168 1 0.13 28 27.51-28.20 178 277 3 0.25 10 9.51-10.20 102 168 1 0.15 28,5 28.21-28.50 182 281 3 0.25 10,5 10.21-10.50 102 175 1 0.15 29 28.51-29.00 182 281 3 0.25 11 10.51-11.20 109 175 1 0.15 29,5 29.01-29.50 182 281 3 0.25 11,5 11.21-11.50 109 182 1 0.15 30 29.51-30.20 182 281 3 0.30 12 11.51-12.20 116 182 1 0.15 30,5 30.21-30.50 186 285 3 0.30 12,5 12.21-12.50 116 182 1 0.15 31 30.51-31.20 186 285 3 0.30 13 12.51-13.20 116 182 1 0.15 31,5 31.21-31.50 186 317 4 0.30 13,5 13.21-13.50 123 189 1 0.15 32 31.51-32.20 193 317 4 0.30 14 13.51-14.20 123 189 1 0.15 32,5 32.21-32.50 193 317 4 0.30 14,5 14.21-14.50 124 204 2 0.15 33 32.51-33.00 193 317 4 0.30 15 14.51-15.20 124 204 2 0.20 33,5 33.01-33.50 193 321 4 0.30 15,5 15.21-15.50 130 210 2 0.20 34 33.51-34.00 197 321 4 0.30 16 15.51-16.20 130 210 2 0.20 34,5 34.01-34.50 197 321 4 0.30 16,5 16.21-16.50 134 214 2 0.20 35 34.51-35.20 197 321 4 0.30 17 16.51-17.20 134 214 2 0.20 35,5 35.21-35.50 197 325 4 0.30 17,5 17.21-17.50 139 219 2 0.20 36 35.51-36.20 201 325 4 0.30 18 17.51-18.20 139 219 2 0.20 36,5 36.21-36.50 201 329 4 0.30 18,5 18.21-18.50 143 223 2 0.20 37 36.51-37.00 201 329 4 0.30 19 18.51-19.20 143 223 2 0.20 37,5 37.01-37.50 201 329 4 0.30 19,5 19.21-19.50 148 228 2 0.20 38 37.51-38.20 205 329 4 0.30 20 19.51-20.20 148 228 2 0.25 38,5 38.21-38.50 205 329 4 0.30 20,5 20.21-20.50 152 232 2 0.25 39 38.51-39.00 205 329 4 0.30 21 20.51-21.20 152 232 2 0.25 39,5 39.01-39.50 205 329 4 0.30 21,5 21.21-21.50 157 237 2 0.25 40 39.51-40.20 205 329 4 0.35 22 21.51-22.20 157 237 2 0.25 206 Main catalogue Hoffmann Group 46
