Clamp stepped With adjustable support screw Tempering steel painted screw strength 8.8 Complete with T-slot screw DIN787 For the lowest clamping height turn the clamp

Clamp stepped With adjustable support screw Tempering steel painted screw strength 8.8 Complete with T-slot screw DIN787 For the lowest clamping height turn the clamp around 036 401 Forked clamp stepped With adjustable support screw. On left and right use the stepped clamping surface allows considerable clamping heights. Without T-slot screw tempering steel painted T-slot width mm 036 401 h mm L mm B2 mm 10 110 8 - 47 100 30 12 14 120 10 - 59 125 40 16 18 160 13 - 67 160 50 20 22 200 16 - 85 200 60 For the lowest clamping height turn the clamp around 036 402 Clamp offset With screw for T-slot DIN787 (8.8) with adjustable support screw nut and washer stepless clamping height adjustment tempering steel painted T-slot width mm 036 402 h mm L mm b2 mm T-slot screw 10 110 22 - 46 100 32 M 10 x 10 x 80 12 120 28 - 58 125 40 M 12 x 12 x 100 14 140 28 - 56 125 40 M 12 x 14 x 100 16 160 36 - 71 160 50 M 16 x 16 x 125 18 180 36 - 69 160 50 M 16 x 18 x 125 036 408 Simple clamps DIN6314 from hardened steel painted Slot width mm 036 408 L mm For screw M a mm 66 070 50 6 10 9 090 60 8 12 11 110 80 10 15 14 140 100 12 14 20 14 141 125 12 14 20 18 180 125 16 18 25 Slot width mm 036 408 L mm For screw M a mm 18 181 160 16 18 25 22 220 160 20 22 30 22 221 200 20 22 30 26 260 200 24 30 26 261 250 24 35 NORGAU 353 Clamping Tools 036 405
